Запчасти Case IH 1690 (B07-3) - ENGINE SPEED HAND CONTROL, HIGH PLATFORM, CAB MODEL, P.I.N. 11213130 AND AFTER (02) - COOLING & FUEL SYSTEMS

1

K204710

LEVER ASSY.

HAND LEVER - speed control

1шт.

2

K607524

NUT

DOMED NUT - 3/8 UNC

1шт.

3

K19482

SPRING WASHER

WASHER - lock, 3/8"

1шт.

4

K623947

PIN

- roll, 1/8 x 3/4"

1шт.

5

K204701

ROD

- hand lever

1шт.

6

K627767

GROMMET

- rod

1шт.

7

K204751

GUIDE

BUSHING - rod

1шт.

8

K626740

WASHER

- Belleville

3шт.

9

K204709

SHIM

PLATE - adjusting

1шт.

10

K204708

DISC

FRICTION DISC - plate

1шт.

11

K605613

SCREW

- 1/4 UNC x 1-5/8", lever stop

1шт.

12

K625232

SPRING

- pressure

1шт.

13

K204748

ROD

TUBE - rod

1шт.

14

K617279

NUT

LOCKNUT - 5/8 UNF, left-hand

1шт.

15

K204705

LEVER

ADJUSTING SLEEVE - 5/8 UNF

1шт.

16

K617056

NUT

LOCKNUT - 5/8 UNF

1шт.

17

K204703

SUPPORT

- tube

1шт.

18

K24887

SPRING

- pressure

1шт.

19

K204986

LEVER

- lock

1шт.

20

K600144

BOLT

- 1/4 UNC x 1-3/8"

1шт.

21

K626341

SPRING WASHER

WASHER - lock

1шт.

22

K607043

NUT

- 1/4 UNC

1шт.

23

K621903

BALL JOINT

SOCKET END - 1/4 UNF

2шт.

24

425-154

JAM NUT,Jam, 1/4"-28, G5

LOCKNUT - 1/4 UNF

2шт.

25

K202336

ROD

- lever to cross shaft

1шт.

26

K621904

BALL JOINT

BALL END - 1/4 UNF

1шт.

27

K626341

SPRING WASHER

WASHER - lock, 1/4"

1шт.

28

K616980

NUT

- 1/4 UNF

1шт.

29

K928177

LEVER

- cross shaft

1шт.

30

K623747

SPLIT PIN/SAFETY PIN

PIN - 5/32 x 3/4"

1шт.

31

K202517

SHAFT

CROSS SHAFT - speed control

1шт.

32

K19472

WASHER

- 3/8"

1шт.

33

K621587

RING, SNAP

RING - snap, 3/8"

1шт.
