Запчасти Case IH 1690 (K09-1) - RAMSHAFT BRACKET (07) - HYDRAULICS

1

K947878

BRACKET

- ramshaft

1шт.

2

K623685

O-RING,0.139" Thk x 4.734" ID, -248, Cl 6, 90 Duro

- 4-3/4", internal diameter

1шт.

3

K623687

O-RING,0.07" Thk x 0.489" ID, -14, Cl 6, 90 Duro

- 5/8", external diameter

2шт.

4

K601380

BOLT

- 5/8 UNC x 8"

4шт.

5

192-25

LOCK WASHER,5/8"

WASHER, LOCK, 5/8"

4шт.

6

86505993

BOLT,Hex, 1/2" - 13 x 4", Gr 5

2шт.

7

192-23

LOCK WASHER,1/2"

WASHER, LOCK, 1/2"

2шт.

8

K928278

COVER

- bracket

1шт.

9

K928279

GASKET

- bracket

1шт.

10

113-113

BOLT,Hex, 5/16" - 18 x 7/8", Gr 5

6шт.

11

192-20

LOCK WASHER,Helical Spring, 0.318" ID, CST, ZND

WASHER, LOCK, 5/16"

6шт.

12

K923237

SKID/SHOE

BREATHER PAD - bracket

1шт.

13

K928282

INDICATOR

SELECTOR PANEL - bracket

1шт.

14

K614943

SCREW

- no. 10 UNF

2шт.

15

K24711

SHIM

CORE PLUG - 5/8"

2шт.

16

K616423

SCREW

PLUG - 9/16 UNF

1шт.

17

K928271

BUSHING

- bracket

1шт.

18

K623579

O-RING,0.21" Thk x 2.225" ID, -331, Cl 5, 75 Duro

- 2-1/2", internal diameter

1шт.

19

219-8

LUBE NIPPLE,1/4" - 28 NPTF

NIPPLE, LUBE, , ANF 1/4"-28 NPT x .54" lg

1шт.

20

K608143

STUD

- 5/16 UNC x 1-1/2"

2шт.

21

K24853

PIN

DOWEL - 1/4 x 11/16"

2шт.
