Запчасти Case IH 1494 (9-460) - INTERIOR AND EXTERIOR TRIM, TRACTORS WITH CAB (09) - CHASSIS/ATTACHMENTS

1

K307727

MAT

floor

1шт.

2

K303230

BRACKET

floor mat

2шт.

3

K651903

WASHER

6 mm, special

4шт.

4

614-6025

BOLT,Hex, M6 x 1 x 25mm, Cl 8.8, Full Thd

- hex, full threads, 6 - 1.0 x 25 mm

4шт.

5

K652106

LOCK NUT

self locking, M6

4шт.

6

K307553

FOAM

TRIM fender, left hand

1шт.

7

K307554

FOAM

TRIM fender, right hand

1шт.

8

K692232

RIVET

FASTENER, Serial Range: trim-fender

12шт.

9

K307578

PLATE

fender, left hand

1шт.

10

K307579

PLATE

fender, right hand

1шт.

11

840-1612

SCREW,Pan, M6 x 12mm, Cl 4.8

- machine, pan Phillips, 6 - 1.0 x 12 mm

4шт.

12

K311527

FOAM

TRIM door post, left hand, Replaces: K307555

1шт.

13

K311526

FOAM

TRIM door post, right hand, Replaces: K307556

1шт.

14

K692232

RIVET

FASTENER, Serial Range: trim-fender

4шт.

15

K307552

FOAM

TRIM roof

1шт.

16

K303333

STRIP

rear

1шт.

17

K303332

STRIP

side, left hand

1шт.

18

K303350

FOAM

STRIP, side, right hand

1шт.

19

K656212

SCREW

no. 7 x 1/2 inch

7шт.

20

K651776

WASHER

5 mm

7шт.

21

K307584

INSULATOR

TRIM seat plate

1шт.

22

K307514

FOAM

INSULATION, front

1шт.

23

K307515

FOAM

INSULATION, fuel sender

1шт.

24

K307516

FOAM

INSULATION, power shift

1шт.
