Запчасти Case IH 1490 (C02-1) - TRANSMISSION CLUTCH RELEASE MECHANISM, LOW PROFILE MODEL PRIOR TO P.I.N. 11182354 (03.1) - CLUTCH

1

K965775

CLUTCH

PEDAL, Includes: Ref. 2

1шт.

2

K628764

BUSHING

2шт.

3

K650805

SCREW

- pedal stop, M8 x 20

1шт.

4

K202056

PIN

PIVOT PIN - clutch pedal

1шт.

5

K19552

GROOVED PIN,1/8" x 1 1/8", Type A

Pin, Grooved, (3.175 x 28.575 mm) 1/8" x 1 1/8", Type A

1шт.

6

K624947

SPRING

- pedal return

1шт.

7

K622205

FORK

END - 5/16 UNF

1шт.

8

K625954

PIN

CLEVIS PIN - 5/16 x 1-3/16" (7.938 x 30.162 mm)

1шт.

9

K623605

PIN

- cotter, 1/16 x 1/2" (1.588 x 12.7 mm)

1шт.

10

425-115

NUT,5/16"-24, G5

LOCKNUT - 5/16 UNF, Fork to push rod

1шт.

11

K950544

CYLINDER,36.32mm Stroke

MASTER CYLINDER - (Girling 73067017)

1шт.

12

K650643

BOLT

SETSCREW - M8 x 25

2шт.

13

K651848

WASHER

- lock 8 mm

2шт.

14

K964572

SEAL KIT

SEAL KIT - master cylinder

1шт.

15

K202212

GUARD

HEAT SHIELD - master cylinder

1шт.

16

K301242

BRACKET

PIPE - reservoir to master cylinder

1шт.

17

K951526

RESERVOIR

Includes: Ref. 18 and 19

1шт.

18

K964488

CAP

FILLER CAP

1шт.

19

K964813

COVER

- green

1шт.

20

K200671

SPRING

CLAMP

1шт.

21

86625206

SCREW,Phillips Drive, Pan HD, #10 - 32 x 1/2"

SETSCREW - no. 10 UNF x 1/2"

2шт.

22

K626340

RING

WASHER - lock 3/16"

2шт.

23

K617080

NUT

- no. 10 UNF

2шт.

24

K301243

CLUTCH

PIPE - master cylinder to slave cylinder

1шт.

25

K301449

BRACKET

- clutch and brake pipes

1шт.

26

K625015

CLIP

- pipe

1шт.

27

K950550

CYLINDER

SLAVE CYLINDER - (Girling 73070023), Includes: Ref. 28

1шт.

28

K964534

SCREW,M12 x 1

- air removal, M12

1шт.

29

413-518

BOLT,Hex, 5/16" - 18 x 1-1/8", Gr 5

SETCREW - 5/16 UNC x 1-1/8"

2шт.

30

K19481

SPRING WASHER

WASHER - lock 5/16"

2шт.

31

9635082

NUT,5/16" - 18, Gr 5

- 5/16 UNC, Includes: Ref. 32

2шт.

32

K964576

SEAL KIT

SEAL KIT - slave cylinder

1шт.
