(N08-1) - ENGINE COVER, FRONT, HIGH PLATFORM

Запчасти Case IH 1490 (N08-1) - ENGINE COVER, FRONT, HIGH PLATFORM (08) - SHEET METAL

Схема запчастей Case IH 1490 - (N08-1) - ENGINE COVER, FRONT, HIGH PLATFORM (08) - SHEET METAL
16
6
17
18
3
21
7
4
8
1
19
9
5
2
20
15
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

K301763

HOOD

NOSE ASSEMBLY, Includes: Ref. 1 - 5

1шт.

1

K301763

HOOD

NOSE - lower

1шт.

2

K302742

SUPPORT

- left-hand

1шт.

3

K302743

SUPPORT

- right-hand

1шт.

4

K624533

SCREW

- self-tapping

6шт.

5

K651848

WASHER

- lock, 8 mm

6шт.

6

K650643

BOLT

- M8 x 24

4шт.

7

K651848

WASHER

- lock, 8 mm

4шт.

8

K651778

WASHER

- 8 mm

4шт.

15

K627874

PLUG

- head lamp adjusters

4шт.

16

K300097

GUARD

GRILLE - lower

1шт.

17

K652464

SCREW

- M5 x 16

4шт.

18

K651846

WASHER, LOCK

WASHER - lock, 5 mm

4шт.

19

K626946

WASHER

- 5 mm, special

4шт.

20

K300238

EMBLEM CASE/IH

MEDALLION - Case logo

1шт.

21

K623280

NUT

- 1/4", special

2шт.
