Запчасти Case IH 1490 (K08-1) - RAMSHAFT BRACKET (07) - HYDRAULICS

1

K952503

BRACKET

RAMSHAFT BRACKET

1шт.

2

K926386

GASKET

- ramshaft bracket to axle case

1шт.

3

K600826

BOLT

- 1/2 UNC x 6", ramshaft bracket to axle case

2шт.

4

K600887

BOLT

- 1/2 UNC x 3-1/4", ramshaft bracket to axle case

2шт.

5

K11518

WASHER

- lock, 1/2", ramshaft bracket to axle case

4шт.

6

K910859

COVER

1шт.

7

K909558

GASKET,1.59mm Thk

1шт.

8

K604477

SCREW

- 5/16 UNC x 5/8"

6шт.

9

K19481

SPRING WASHER

WASHER - lock, 5/16"

6шт.

10

K923237

SKID/SHOE

BREATHER PAD

1шт.

11

K951967

INDICATOR

SELECTOR PANEL

1шт.

12

K614943

SCREW

- No. 10 UNF

2шт.

13

K947405

KNOB

POINTER

1шт.

14

K623936

PIN, ROLL

PIN - 1/8 x 3/4" (3.175 x 19.05 mm)

1шт.

15

K919362

CONTROL LEVER

SELECTOR ROD

1шт.

16

K623815

PLUG

CORE PLUG - 5/8" (15.875 mm)

2шт.

17

K923284

PLUG

- 9/16 UNF (14.288 mm) not North America

1шт.

17

K616423

SCREW

PLUG - 9/16 UNF (14.288 mm) North America only

1шт.

18

219-8

LUBE NIPPLE,1/4" - 28 NPTF

NIPPLE, LUBE, , ANF 1/4"-28 NPT x .54" lg

1шт.

19

K608143

STUD

- 5/16 UNC x 1-1/2", control, Serial Range: valve-bracket

2шт.

20

K19481

SPRING WASHER

WASHER - lock, 5/16", control, Serial Range: valve-bracket

2шт.

21

9635082

NUT,5/16" - 18, Gr 5

- 5/16" UNC, control valve to bracket

2шт.

22

K24853

PIN

DOWEL - 1/4 x 11/16" (6.35 x 17.462 mm) control, Serial Range: valve-bracket

2шт.

23

K913758

BUSHING,57.19mm ID x 61.38mm OD x 28.83mm L

- ramshaft

1шт.

24

K623579

O-RING,0.21" Thk x 2.225" ID, -331, Cl 5, 75 Duro

- 2-1/4" (57.15 mm) internal diameter

1шт.
