Запчасти Case IH 1390 (A-11) - MANIFOLDS AND MUFFLER (01) - ENGINE

1

K201352

MANIFOLD

- intake

1шт.

2

K906744

MANIFOLD

- exhaust

1шт.

3

K921730

MANIFOLD GASKET

- intake manifold

4шт.

4

K907344

MANIFOLD GASKET

- exhaust manifold

2шт.

5

K907343

GASKET

- exhaust manifold

1шт.

6

280136

NUT,3/8"-16, G8

17шт.

7

K608209

STUD

- 3/8 UNC x 2-1/4 inch

2шт.

8

K68327

GASKET

-, Serial Range: manifold-flange

1шт.

9

K204220

FLANGE

- exhaust

1шт.

10

K302951

MUFFLER

- exhaust

1шт.

REF 10 THIS MUFFLER HAS A 2 1/4" O.D. INLET TUBE, IF DLR LOOKING FOR A 2" INLET TUBE TRY PART NOS. K304290 PER QUALITY COMMENTS

1шт.

11

K201313

SWITCH

- vacuum

1шт.

12

K928668

PIPE,0.25" OD x 14" L

- exhaust manifold drain

1шт.

13

K626051

FITTING

CONNECTOR - 1/8 inch BSP

1шт.

14

K622402

FERRULE

SLEEVE - 1/4 inch

1шт.

15

K617421

PIPE UNION NUT

- 1/8 inch BSP

1шт.

16

K619528

PLUG

- 7/8 inch UNF

1шт.

17

K626784

WASHER,23.24mm ID x 33.34mm OD x 2.34mm Thk

- sealing

1шт.

18

K928523

GLOW PLUG

THERMOSTART - fuel (CAV 1854102)

1шт.
