Запчасти Case IH 1194 (5-094) - PUMP, POWER STEERING (05) - STEERING

1

K947346

PULLEY

1шт.

2

K952370

GUARD

- pump pulley

1шт.

3

K203723

MOUNTING PARTS

PLATE - mounting

1шт.

4

K650327

SCREW

BOLT - M6 x 16 mm

4шт.

5

K651827

SPRING

WASHER - lock, 6 mm

4шт.

6

K202440

STRAP

- adjusting

1шт.

7

88206

BOLT,Hex, 3/8" - 16 x 1", Gr 5

1шт.

8

K19472

WASHER

- 3/8 inch (10 mm)

1шт.

9

280136

NUT,3/8"-16, G8

1шт.

10

K600207

BOLT

- 5/16 UNC x 1-3/4 inch

1шт.

11

K19481

SPRING WASHER

WASHER - lock, 5/16 inch

1шт.

12

K947348

SUPPORT

BRACKET - pump

1шт.

13

86632558

JAM NUT,Jam, 1/2"-13, G5

NUT - 1/2 inch UNC

1шт.

14

K19484

LOCK WASHER

WASHER - lock, 1/2 inch

1шт.

15

K600403

BOLT

- 3/8 UNC x 1-3/8 inch

2шт.

16

K19482

SPRING WASHER

WASHER - lock, 3/8 inch

2шт.

17

K912196

V-BELT

Pump and fan

2шт.

18

K207418

PUMP

ASSEMBLY - Hobourn-Eaton, Includes: Ref. 19 - 24

1шт.

19

K260945

RESERVOIR

- pump

1шт.

20

K260952

BALL

BEARING - ball

1шт.

21

K260960

SHAFT

ASSEMBLY

2шт.

22

K260961

GASKET KIT

KIT - seals, pump

1шт.

23

K617374

NUT

- 3/8 inch UNF

1шт.

24

K19602

KEY

- Woodruff No. 404

1шт.

25

K960754

BEARING

1шт.
