Запчасти Case IH 1194 (8-222) - RAMSHAFT BRACKET (08) - HYDRAULICS

1

K913003

BRACKET

- ramshaft

1шт.

2

K926386

GASKET

- bracket to axle housing

1шт.

3

K600822

BOLT

- 1/2 UNC x 5 inch

2шт.

4

K600815

BOLT

- 1/2 UNC x 3-1/4 inch

2шт.

5

K11518

WASHER

- lock, 1/2 inch

4шт.

6

K910859

COVER

1шт.

7

K909558

GASKET,1.59mm Thk

-, Serial Range: cover-bracket

1шт.

8

K604477

SCREW

- 5/16 UNC x 5/8 inch

4шт.

9

K19481

SPRING WASHER

WASHER - lock, 5/16 inch

4шт.

10

K923237

SKID/SHOE

PAD - breather

1шт.

11

K909542

WASHER

PANEL - selector

1шт.

12

K614943

SCREW

- No. 10 UNF

2шт.

13

K24711

SHIM

PLUG - core, 5/8 inch (16 mm)

2шт.

15

K616423

SCREW

PLUG - 9/16 inch UNF, special (North America only)

1шт.

15

K923284

PLUG

- 9/16 inch UNF (Not North America)

1шт.

16

K912012

BUSHING

1шт.

17

K623538

O-RING,6.99mm Thk x 50.16mm ID, 60 Duro

- 2 inch (51 mm) internal diameter

1шт.

18

219-8

LUBE NIPPLE,1/4" - 28 NPTF

NIPPLE, LUBE, , ANF 1/4"-28 NPT x .54" lg

1шт.

19

K608143

STUD

- 5/16 UNC x 1-1/2 inch

2шт.

20

K24853

PIN

DOWEL - 1/4 x 11/16 inch

2шт.

21

K19481

SPRING WASHER

WASHER - lock, 5/16 inch

2шт.

22

9635082

NUT,5/16" - 18, Gr 5

- 5/16 inch UNF

2шт.
