Запчасти Case IH 1030 (048) - STARTER (04) - ELECTRICAL SYSTEMS

1

A34442

STARTER MOTOR

STARTER ASSY. - (Delco #1114125), Includes Ref: 2 - 104

1шт.

1

104255A1R

REMAN-STARTER

1030, Reman For New PN A34442

1шт.

1

104255A1C

CORE-STARTER

Return Part Number

1шт.

1

104215A2R

REMAN-STARTER

Remanufactured Starter

1шт.

1

104215A1C

CORE-STARTER

Return Part Number

1шт.

2

A40897

FRAME

FRAME ASSY. - comm. end, Includes Ref: 3 - 7

1шт.

3

221-1041

PLUG

PLUG - oil wick hole

1шт.

4

R15023

WICK

WICK - oil (5/16 x 2" felt)

1шт.

5

A41923

PLUG

PLUG - oil reservoir (15/16" dia. felt)

1шт.

6

41-57

PLUG,Exp, 1 1/32"

PLUG - oil reservoir hole (1-1/32" exp.)

1шт.

7

A25336

BUSHING

BUSHING - comm. end (9/16 x 3/4 x 31/32")

1шт.

9

D31954

O-RING,0.139" Thk x 4.11" ID, -243, Cl 5, 75 Duro

"O" RING - comm. end frame

1шт.

10

114-1

BOLT,Hex, 1/4" - 28 x 1", Gr 5

BOLT, , Commutator end to coil housing Hex, 1/4"-28 x 1", G5

4шт.

11

192-19

LOCK WASHER,Helical Spring, 0.256" ID, CST, ZND

WASHER, LOCK, 1/4"

4шт.

12

A41914

SUPPORT

PLATE - support

1шт.

13

A41457

INSULATOR

SPACER - brush mtg., ring

1шт.

14

173-274

SCREW,Sl Rnd Hd, #8 - 32 x 1/2"

BOLT - spacer mtg. ring

3шт.

15

192-16

LOCK WASHER,Helical Spring, #8, 0.17" ID, CST, ZND

Washer, Lock, #8

3шт.

16

A41970

SPARE PART WASHER - spacer mounting

3шт.

17

A41921

PLATE

RING - brush mounting

1шт.

18

A41916

WASHER

WASHER - brush holder screw insulating

8шт.

19

A42425

NOZZLE HOLDER

HOLDER - brush

4шт.

20

A40674

NOZZLE HOLDER

INSULATION - brush holder

2шт.

21

A41454

SPARE PART PLATE - brush holder (thin)

2шт.

21

A41455

SPACER

PLATE - brush holder (heavy)

2шт.

25

A40891

BRUSH, COMMUTATOR

BRUSH BRUSH - starter

8шт.

26

A25393

SPRING

SPRING - brush tension

8шт.

27

A41915

SPARE PART STUD - brush spring carrier, insulated brush

2шт.

27

A41972

SCREW,#10 - 32 x 1.36, 0.4"

STUD - brush spring carrier, grounded brush

2шт.

28

A41959

SCREW,#10 - 32 x 3/8"

SCREW - brush holder, grounded

2шт.

28

A41974

SCREW,#10 - 32 x 5/8"

SCREW - brush holder, insulated

2шт.

29

192-18

LOCK WASHER,Helical Spring, #10, 0.196" ID, CST, ZND

WASHER, LOCK, #10

8шт.

30

174-211

SCREW,Sl Rnd Hd, #8 - 32 x 5/16"

SCREW - brush retaining

8шт.

31

A41918

INSULATOR

INSULATOR - terminal stud

1шт.

32

D30006

WASHER

WASHER - term. stud (flat)

1шт.

33

192-113

LOCK WASHER,1/2"

WASHER - term. stud ( lock) 1/2"

2шт.

34

129-145

JAM NUT,Jam, 1/2"-13, G5

NUT, , Terminal stud Jam, 1/2"-13, G5

1шт.

35

129-105

NUT,Hex, 1/2" - 13, Gr 5

NUT, 1/2"-13, G5

1шт.

40

A40895

COIL

COIL ASSY. - field

1шт.

41

A40896

STUD

STUD - starter terminal

1шт.

42

R15115

SHOE

SHOE - pole

4шт.

43

74-610

SCREW,3/8" - 24 x 5/8"

SCREW - pole shoes

8шт.

44

A41920

INSULATOR

INSULATION - field coil

1шт.

45

NSS

NOT SOLD SEPARAT

INSULATION - jumper wire junction

2шт.

46

NSS

NOT SOLD SEPARAT

FRAME - field

1шт.

47

A41957

PLATE

COVER - brush inspection

2шт.

48

A41849

GASKET

GASKET - inspection cover

2шт.

49

171-207

SCREW,Flat Hd, 1/4" x 1/2"

SCREW - inspection cover ret.

4шт.
