Артикул
Название
Примечание
Количество
1
700-445
TEE,13/16" - 16 Male ORFS x 13/16" - 16 Male ORFS x M22 x 1.5 Male ORB
Inc 2, 3
2шт.
2
238-6014
O-RING,0.07" Thk x 0.489" ID, -14, Cl 6, 90 Duro
14шт.
3
637-63193
O-RING,2.2mm Thk x 19.3mm ID, Cl 6, 90 Duro
4шт.
4
700-102
HYD CONNECTOR,13/16" - 16 Male ORFS x M18 x 1.5 Male ORB
Incl. 2, 6
3шт.
5
449815A2
TUBE
1шт.
6
637-63153
O-RING,2.2mm Thk x 15.3mm ID, Cl 6, 90 Duro
4шт.
7
375663A1
HOSE ASSY.
2165 mm (85 in)
1шт.
7
87424325
HOSE ASSY.
2165 mm (85")
1шт.
Arctic QUADTRAC Tractor Application
1шт.
8
87413873
HOSE ASSY.
1898mm (75 in)
1шт.
8
87424326
HOSE ASSY.
1898mm (75 in)
1шт.
Arctic QUADTRAC Tractor Application
1шт.
9
214-1420
HOSE CLAMP,#20, 0.81" - 1.75", Type F Worm
6шт.
10
451013A1
TUBE
2шт.
11
340971A1
HOSE
1219 mm (48 in), Cut From : 31-2755
1шт.
12
87388066
TUBE,25.40mm OD x 593, 199mm L
1шт.
13
87390647
HOSE
1шт.
14
395933A1
HOSE,1.00" ID x 15.00"
Cut from S118383
1шт.
15
87414080
HOSE ASSY.
970 mm (39 in)
1шт.
15
87424331
HOSE ASSY.
990 mm (39")
1шт.
Arctic QUADTRAC Tractor Application
1шт.
16
87672094
VALVE
Regulator, See Figure: 08-14
1шт.
17
700-169
HYD CONNECTOR,13/16" - 16 Male ORFS x M16 x 1.5 Male ORB
Inc. 2, 19
1шт.
18
238-5011
O-RING,0.07" Thk x 0.301" ID, -11, Cl 5, 75 Duro
2шт.
19
637-63133
O-RING,2.2mm Thk x 13.3mm ID, Cl 6, 90 Duro
1шт.
20
413338A1
TUBE
1шт.
21
449800A1
TUBE
1шт.
22
700-305
ELBOW,90 Degree Elbow, 13/16" - 16 Male ORFS x M18 x 1.5 Male ORB
Incl. 2, 6
1шт.
23
238-5111
O-RING,0.103" Thk x 0.424" ID, -111, Cl 5, 75 Duro
2шт.
24
87400028
ORIFICE
Pinnion Cover
2шт.
25
87307521
TUBE,9.40 mm ID x 12.70 mm OD
1шт.
26
701-301
ELBOW,90 Degree Elbow, 13/16" - 16 Male ORFS x 13/16" - 16 Male ORFS
Incl. 2
1шт.
27
449813A2
TUBE
1шт.
28
701-903
NUT,13/16" - 16
3шт.
29
701-121
UNION,13/16" - 16 Male ORFS x 13/16" - 16 Male ORFS
Inc. 2
2шт.
30
394302A1
PLATE
Mounting
2шт.
31
238-6012
O-RING,0.07" Thk x 0.364" ID, -12, Cl 6, 90 Duro
3шт.
32
627-8025
BOLT,Hex, M8 x 1.25 x 25mm, Cl 10.9, Full Thd
2шт.
34
829-1408
NUT,Hex, M8 x 1.25, Cl 10.9
4шт.
35
87307544
TUBE,9.40 mm ID x 12.70 mm OD x 43.00, 64.23 mm L
1шт.
36
392690A1
COUPLING
Inc. 35
1шт.
37
399032A1
CAP
Dust
1шт.
38
390348A1
STEM
M33 orb x barb, Axle Drain, Inc. 39
2шт.
39
637-64296
O-RING,2.9mm Thk x 29.6mm ID, Cl 6, 90 Duro
2шт.
40
334783A1
SLEEVE
1шт.
41
L18331
CABLE TIE,375.9mm L, Nylon, Black
CABLE STRAP 15"
2шт.
42
201-305
ELBOW,90 Degree Elbow, 13/16" - 16 Male ORFS x 3/4" - 16 Male ORB
1/2 or x 13/16 fc sl, Incl. 43, 2
4шт.
43
637-63093
O-RING,2.2mm Thk x 9.3mm ID, Cl 6, 90 Duro
1шт.
44
700-447
TEE,13/16" - 16 Male ORFS x 13/16" - 16 Male ORFS x M22 x 1.5 Male ORB
Inc. 2, 6
1шт.
45
700-162
HYD CONNECTOR,13/16" - 16 Male ORFS x M22 x 1.5 Male ORB
Inc. 2, 3
2шт.
46
71100209
PLUG,Hex Soc, 3/4"-16 ORB
Incl 47
1шт.
47
237-6012
O-RING,0.116" Thk x 0.924" ID, -912, Cl 6, 90 Duro
1шт.
48
434727A1
MOTOR-PUMP
Axle Air / Lube
1шт.
49
451015A1
TUBE
Final Drive, Long
2шт.
50
409614A1
TUBE
Return
1шт.
51
253105A1
U-BOLT,Coined, M8 x 1.25 x 33.8 x 50mm
BOLT "U"
2шт.
52
396490A1
U-BOLT
BOLT "U"
2шт.
53
895-11008
WASHER,9mm ID x 16mm OD x 1.6mm Thk
12шт.
54
832-10408
NUT,M8 x 1.25, Cl 8.8
8шт.
Выбрано товаров: 60
