Запчасти Case IH STX425 (01-18) - PICTORIAL INDEX - HYDRAULIC FAN DRIVE (00) - PICTORIAL INDEX

1

Cooler, Hydraulic Oil, See Figure 08-45

1шт.

2

Motor, Hydraulic Fan, See Figure 02-03 (01)

1шт.

3

Hose, Fan Motor Supply, See Figure 08-44

1шт.

4

Tube, Fan Motor Supply, See Figure 08-44

1шт.

5

Hose, Case Drain, See Figure 08-44

1шт.

6

Tube, Case Drain, See Figure 08-44

1шт.

7

Tube, Fan Motor Return To Tank, See Figure 08-44

1шт.

8

Hose, Fan Motor To Cooler, See Figure 08-44

1шт.

9

Hose, Cooler Return To Tank, See Figure 08-44

1шт.

10

Hose, Fan Motor Return To Tank, See Figure 08-44

1шт.

11

Hose, Pump Return To Tank, See Figure 08-44

1шт.

12

Hose, Case Drain, See Figure 08-44

1шт.

13

Hose, Gear Pump Supply, See Figure 08-44

1шт.

14

Tube, Gear Pump Supply, See Figure 08-44

1шт.

15

Pump, See Figure 08-44 (01)

1шт.
