Запчасти Case IH STX425 (01-14) - PICTORIAL INDEX - ELECTRONIC HITCH CIRCUIT (00) - PICTORIAL INDEX

1

Cylinder, Three Point Hitch Lift, See Figure 08-42

1шт.

2

Hose, Right-Hand Cylinder Supply, See Figure 08-41

1шт.

3

Hose, Cylinder Return To Tank, See Figure 08-41

1шт.

4

Tube, Return From Hitch Valve, See Figure 08-41

1шт.

5

Hose, Return To Tank, See Figure 08-41

1шт.

6

Hose, Left-Hand Cylinder Supply, See Figure 08-41

1шт.

7

Hose, Left-Hand Cylinder Return, See Figure 08-41

1шт.
