Запчасти Case IH STX425 (08-11) - HYDRAULIC TANK, WHEEL TRACTOR (08) - HYDRAULICS

1

87313212

TANK

1шт.

2

341858A1

LADDER

Front, Right-Hand

1шт.

3

341859A1

LADDER

Rear, Left-Hand

1шт.

4

87301185

STEP

5шт.

5

87408715

FILTER STRAINER

1шт.

6

254253A1

CAP

Oil Filler, (For 2.40" hole) if used

1шт.

Order Cap 254253A1 for Models Built BSN JEE0107140. If Tank has been Replaced by Tank 87313212. Then Order Cap 325737A1.

1шт.

6

325737A1

CAP

Oil Filler (For 2" hole)

1шт.

7

217-410

PLUG,Hex Hd, 1/2" - 14 NPT

1шт.

8

1971726C1

BREATHER,1/4" - 18

2шт.

9

435031A1

GASKET

1шт.

10

435030A1

COVER

Access

1шт.

11

832-10408

NUT,M8 x 1.25, Cl 8.8

8шт.

12

827-10045

BOLT,Hex, M10 x 1.5 x 45mm, Cl 10.9

8шт.

13

832-10410

NUT,M10 x 1.5, Cl 8

26шт.

14

376530A1

SUPPORT

Step

2шт.

15

811-10025

CARRIAGE BOLT,Sht Sq Nk, M10 x 1.5 x 25mm, Cl 8.8

2шт.

16

363226A1

BUMPER

Rubber

1шт.

17

895-11010

WASHER,11mm ID x 20mm OD x 2mm Thk

22шт.

18

627-10035

BOLT,Hex, M10 x 1.5 x 35mm, Cl 10.9, Full Thd

16шт.

19

896-15010

WASHER,11mm ID x 24mm OD x 3mm Thk

11 x 24 x 3,0 mm

8шт.

20

217-445

PLUG,Hex Soc, 1-1/4" - 11-1/2 NPTF

1шт.

21

435032A1

LOCK NUT

1шт.

22

349869A1

CHANNEL

1шт.

23

355179A1

HOSE

Sight Gauge

1шт.

24

352767A1

FITTING

2шт.

25

337248A1

O-RING,0.139" Thk x 0.484" ID, -206, Cl 5, 75 Duro

4шт.

26

844-10035

BOLT,Hex, M10 x 35mm, Cl 8.8

2шт.
