Артикул
Название
Примечание
Количество
1
700-305
ELBOW,90 Degree Elbow, 13/16" - 16 Male ORFS x M18 x 1.5 Male ORB
Incl. 2, 3
1шт.
3
637-63153
O-RING,2.2mm Thk x 15.3mm ID, Cl 6, 90 Duro
1шт.
4
437144A1
HOSE ASSY.
1733 mm (68 in)
1шт.
4
87424329
HOSE ASSY.
1733 mm (68 in)
1шт.
Arctic QUADTRAC Tractor Application
1шт.
5
701-301
ELBOW,90 Degree Elbow, 13/16" - 16 Male ORFS x 13/16" - 16 Male ORFS
Incl. 6, 7
2шт.
7
701-903
NUT,13/16" - 16
1шт.
8
449821A2
TUBE
1шт.
9
86992953
HOSE ASSY.
1715 mm (67-1/2 in)
1шт.
9
87424333
HOSE ASSY.
1715 mm (67-1/2 in)
1шт.
Arctic QUADTRAC Tractor Application
1шт.
10
515-23206
CLAMP,13/16", Insul, 3/8" Bolt
3шт.
11
895-11008
WASHER,9mm ID x 16mm OD x 1.6mm Thk
1шт.
12
829-1408
NUT,Hex, M8 x 1.25, Cl 10.9
1шт.
13
627-10030
BOLT,Hex, M10 x 1.5 x 30mm, Cl 10.9, Full Thd
4шт.
14
416102A1
SUPPORT
Bracket
1шт.
16
627-8025
BOLT,Hex, M8 x 1.25 x 25mm, Cl 10.9, Full Thd
1шт.
17
434727A1
MOTOR-PUMP
Axle Air / Lube
2шт.
18
201-332
ELBOW,90 Degree Elbow, 13/16" - 16 Male ORFS x 9/16" - 18 Male ORB
Incl 2, 19
3шт.
19
637-63093
O-RING,2.2mm Thk x 9.3mm ID, Cl 6, 90 Duro
3шт.
20
450905A1
TEE
Special, 1/2 or x fc sl, Inc. 2, 19
1шт.
21
449817A2
TUBE
1шт.
22
86992542
TUBE,12.70 mm OD
1шт.
23
701-121
UNION,13/16" - 16 Male ORFS x 13/16" - 16 Male ORFS
Inc. 2
2шт.
24
701-903
NUT,13/16" - 16
2шт.
25
700-162
HYD CONNECTOR,13/16" - 16 Male ORFS x M22 x 1.5 Male ORB
Inc. 2, 26
1шт.
26
637-63193
O-RING,2.2mm Thk x 19.3mm ID, Cl 6, 90 Duro
1шт.
27
87400117
HOSE ASSY.,12.7mm ID x 2299mm L
2299 mm (90-1/2 in)
1шт.
Used On Applications Without PTO
1шт.
27
87424335
HOSE ASSY.
2299 mm (90-1/2 in)
1шт.
Used On Applications Without PTO
1шт.
28
449794A1
TUBE
1шт.
29
449825A1
TUBE
1шт.
30
449823A1
TUBE
1шт.
31
449805A1
HOSE ASSY.
2413 mm (95 in)
4шт.
31
87424330
HOSE ASSY.
2413 mm (95 in)
1шт.
Arctic QUADTRAC Tractor Application
1шт.
32
829-1310
NUT,M10, Cl 10
4шт.
34
700-102
HYD CONNECTOR,13/16" - 16 Male ORFS x M18 x 1.5 Male ORB
Incl. 35, 36
2шт.
36
637-63153
O-RING,2.2mm Thk x 15.3mm ID, Cl 6, 90 Duro
1шт.
37
L18331
CABLE TIE,375.9mm L, Nylon, Black
CABLE STRAP
1шт.
Выбрано товаров: 45
