Запчасти Case IH STX425 (01-07[01]) - PICTORIAL INDEX - CHARGE PUMP AND BRAKE CIRCUIT, 500 SERIES AXLE, WHEEL TRACTOR, BSN JEE0102001 (00) - PICTORIAL INDEX

Схема запчастей Case IH STX425 - (01-07[01]) - PICTORIAL INDEX - CHARGE PUMP AND BRAKE CIRCUIT, 500 SERIES AXLE, WHEEL TRACTOR, BSN JEE0102001 (00) - PICTORIAL INDEX
12
7
13
13
8
1
16
9
11
3
4
2
14
5
15
6
7
12
11
10

Артикул

Название

Примечание

Количество

1

Pump, Gear, See Figure 08-27

1шт.

2

Tube, Gear Pump Supply From Tank, See Figure 08-20, 08-24

1шт.

3

Hose, Gear Pump To Charge Return Tube, See Figure 08-20, 08-24

1шт.

4

Tube, Charge Return To Filter, See Figure 08-08

1шт.

5

Fillter, Tow Valve Assembly, See Figure 08-04

1шт.

6

Hose, Service Brake Line, See Figure 07-06

1шт.

7

Hose, Tow Valve Supply For Rear Axle Park Brake, See Figure 07-07, 07-08

1шт.

8

Hose, Tow Valve Supply For Front Axle Park Brake, See Figure 07-07, 07-08

1шт.

9

Valve, Regulator, See Figure 08-13

1шт.

10

Hose, Regulator Output To Brake Valve, See Figure 07-07, 07-08

1шт.

11

Valve, Brake, See Figure 07-02

1шт.

12

Hose, Brake Valve Return To Tank, See Figure 07-07, 07-08

1шт.

13

Hose, Service Brake To Rear Axle, See Figure 07-06

1шт.

14

Hose, Sevice Brake To Front Axle, See Figure 07-06

1шт.

15

Solenoid, Differential Lock, See Figure 08-43

1шт.

16

Tube, Differential Lock, See Figure 07-08

1шт.
