Артикул
Название
Примечание
Количество
310788A1
VALVE
main, consists of: Ref. 1, 4 - 81
1шт.
311134A1
VALVE
auxiliary, right-hand, consists of: Ref. 2, 4 - 81
1шт.
311137A1
VALVE
auxiliary, left-hand, consists of: Ref. 3, 4 - 81
1шт.
1
NSS
NOT SOLD SEPARAT
BODY
1шт.
2
NSS
NOT SOLD SEPARAT
BODY
1шт.
3
NSS
NOT SOLD SEPARAT
BODY
1шт.
310940A1
SPOOL
consists of: Ref. 4 - 11
1шт.
4
NSS
NOT SOLD SEPARAT
SPOOL
1шт.
6
311003A1
WASHER
1шт.
7
310941A1
SPRING SEAT
1шт.
8
311002A1
SPRING
1шт.
9
310942A1
SPRING SEAT
1шт.
10
237-6002
O-RING,0.064" Thk x 0.239" ID, -902, Cl 6, 90 Duro
1шт.
11
246405A1
STUD
1шт.
310982A1
DETENT
auxiliary, consists of: Ref. 12 - 38
1шт.
310979A1
COVER
detent, consists of: Ref. 12 and 13
1шт.
12
NSS
NOT SOLD SEPARAT
COVER
1шт.
13
1976937C1
SEAT, VALVE,7.22mm Bore, 2.43mm Rod, 10.18mm W
1шт.
14
G108912
WASHER
1шт.
15
864-6025
HEX SOC SCREW,M6 x 25mm, Cl 8.8
3шт.
16
211-1007
BALL,7/32" Dia
Gr 24, CRS
8шт.
17
G108911
WASHER
1шт.
G108921
PISTON
detent, consists of: Ref. 18 - 22
1шт.
18
G108908
PISTON
1шт.
19
G108922
BACK-UP RING
1шт.
20
238-6020
O-RING,0.07" Thk x 0.864" ID, -20, Cl 6, 90 Duro
1шт.
22
G108728
BACK-UP RING
1шт.
23
G110152
SPRING
1шт.
321361A1
RETAINER
consists of: Ref. 24 - 26
1шт.
24
NSS
NOT SOLD SEPARAT
RETAINER
1шт.
25
G107780
VALVE, CHECK
rubber
1шт.
26
321360A1
O-RING,0.8mm Thk x 27mm ID, Cl 5, 75 Duro
1шт.
27
100-21118
SNAP RING,1.188", Int, #118
1шт.
28
238-6015
O-RING,0.07" Thk x 0.551" ID, -15, Cl 6, 90 Duro
1шт.
29
238-6011
O-RING,0.07" Thk x 0.301" ID, -11, Cl 6, 90 Duro
1шт.
30
G108918
ORIFICE
1шт.
31
G110279
VALVE POPPET
1шт.
32
G110281
SPRING CUP
2шт.
33
G109275
SPRING
1шт.
34
G110289
BACK-UP RING
1шт.
35
238-5004
O-RING,0.07" Thk x 0.07" ID, -4, Cl 5, 75 Duro
1шт.
36
238-6012
O-RING,0.07" Thk x 0.364" ID, -12, Cl 6, 90 Duro
1шт.
37
G110300
PLUG
1шт.
38
425-1510
JAM NUT,Jam, 5/8"-18, G5
1шт.
39
65457C1
SEAL,19.04mm ID x 25.5mm OD x 3.17mm Thk
1шт.
1542563C1
KIT
logic, consists of: Ref. 41 - 45
1шт.
41
1994580C1
PLUG
1шт.
42
1543329C1
VALVE POPPET,7mm ID x 13.8mm OD x 27mm L
1шт.
43
1994581C1
SPRING,6.1mm OD x 31.1mm L
1шт.
44
G108723
RING,14.34mm ID x 16.94mm OD x 1.32mm Thk
1шт.
45
238-6015
O-RING,0.07" Thk x 0.551" ID, -15, Cl 6, 90 Duro
1шт.
278550A1
CHECK VALVE
load, consists of: Ref. 46 - 58
1шт.
278550A2R
REMAN-HYD VALVE
STX375 BSN JEE0099501, STX440, Reman For New P/N 278550A1
1шт.
278550A2C
CORE-VALVE HYD
Return Number
1шт.
46
NSS
NOT SOLD SEPARAT
BODY
1шт.
47
NSS
NOT SOLD SEPARAT
POPPET valve
1шт.
48
NSS
NOT SOLD SEPARAT
Poppet, Lock Check Pilot
1шт.
49
1957964C1
RETAINER
1шт.
50
NSS
NOT SOLD SEPARAT
CAP
1шт.
51
1957817C1
VALVE SPRING
1шт.
52
237-6010
O-RING,0.097" Thk x 0.755" ID, -910, Cl 6, 90 Duro
2шт.
53
G108727
BACK-UP RING,13.27mm ID x 15.87mm OD x 1.32mm Thk
1шт.
54
238-6016
O-RING,0.07" Thk x 0.614" ID, -16, Cl 6, 90 Duro
1шт.
55
G103862
BACK-UP RING,15.77mm ID x 18.67mm OD x 1.32mm Thk
1шт.
56
238-6015
O-RING,0.07" Thk x 0.551" ID, -15, Cl 6, 90 Duro
1шт.
57
G108723
RING,14.34mm ID x 16.94mm OD x 1.32mm Thk
1шт.
58
NSS
NOT SOLD SEPARAT
SPRING
1шт.
1957907C1
PISTON ASSY
consists of: Ref. 59 - 61
1шт.
59
1957862C1
PISTON
1шт.
60
1957861C1
WASHER
1шт.
61
1957859C1
SNAP RING
1шт.
62
86632547
PLUG,Hex, 5/16"-24 ORB
Includes Ref. 63
1шт.
63
238-6006
O-RING,0.07" Thk x 0.114" ID, -6, Cl 6, 90 Duro
1шт.
140906A3
VALVE
flow control, consists of: Ref. 64 - 67
1шт.
64
NSS
NOT SOLD SEPARAT
SLEEVE
1шт.
65
183491A1
PLUG
1шт.
66
NSS
NOT SOLD SEPARAT
SPOOL
1шт.
67
238-6013
O-RING,0.07" Thk x 0.426" ID, -13, Cl 6, 90 Duro
7/16 ID x 1/16
1шт.
68
185448A2
SPRING
1шт.
69
292258A1
WASHER
3шт.
111205A1
VALVE
flow, consists of: Ref. 70 - 80
1шт.
70
G108957
RACE,9.58mm ID x 20.37mm OD x 1.59mm Thk
1шт.
71
F13537
THRUST BEARING
1шт.
72
G108956
RACE,9.58mm ID x 20.37mm OD x 0.81mm Thk
1шт.
73
238-5110
O-RING,0.103" Thk x 0.362" ID, -110, Cl 5, 75 Duro
3/32 ID x 3/4; 5
1шт.
74
237-6010
O-RING,0.097" Thk x 0.755" ID, -910, Cl 6, 90 Duro
1шт.
75
111206A1
PLUG
1шт.
76
G101060
WASHER
1шт.
77
111207A1
INSERT
2шт.
78
178-896
SET SCREW,Hex Soc, #10-32 x 3/16"
2шт.
1980302C2
ROD
consists of: Ref. 79 and 80
1шт.
79
1980228C3
ROD, ADJUSTMENT
ROD, ADJUSTING
1шт.
80
38-1812
LOCK PIN,1/8" x 3/4", Slotted
1/8 x 3/8 in.
1шт.
81
321742A1
PLUG
Includes: O-ring
1шт.
21
238-6021
O-RING,15/16 X 1 - 1/16, Cl 6
1шт.
Выбрано товаров: 97
