Запчасти Case IH STX325 (01-03[03]) - PICTORIAL INDEX - STEERING, FRONT AXLE WITH ACCUSTEER (00) - PICTORIAL INDEX

1

PUMP Piston, High Output Hydraulics, See Figure 08-21

1шт.

2

PUMP Gear, See Figure 08-22

1шт.

3

HOSE Priority Valve Supply, See Figure 08-19 (02)

1шт.

4

VALVE Priority, High Output Hydraulics, See Figure 08-23

1шт.

5

HOSE Steering Load Sense, See Figure 08-19 (02)

1шт.

6

HOSE Steering Return, See Figure 08-19 (02)

1шт.

7

HOSE Steering Control, To Right-Hand Cylinder, See Figure 05-01 (03)

1шт.

8

HOSE Steering Control, To Left-Hand Cylinder, See Figure 05-01 (03)

1шт.

9

HOSE Steering Control Supply, See Figure 08-19 (02)

1шт.

10

CYLINDER Steering, See Figure 05-03 (03)

1шт.

11

CYLINDER Steering, With Sensor, See Figure 05-03 (04)

1шт.

12

VALVE Steering Control, See Figure 05-04 (02)

1шт.
