Запчасти Case IH STX325 (04-24) - HARNESS MAIN CAB, DELUXE AND LUXURY CABS (04) - ELECTRICAL SYSTEMS

381260A1

BOARD, PRINTED CIRCU

IT main electronics, see Figure 04-25, consists of: Ref. 1

1шт.

1

378020A2

HARNESS

main cab

1шт.

2

227739A2

POWER SOCKET

power

3шт.

3

383986A1

RIVET

12шт.

4

895-11003

WASHER,3.2mm ID x 7mm OD x 0.5mm Thk

12шт.

5

20-2041T2

CIRCUIT BREAKER

1шт.

6

895-11006

WASHER,6.6mm ID x 12mm OD x 1.6mm Thk

4шт.

7

840-1616

SCREW,Pan, M6 x 16mm, Cl 4.8

2шт.

8

284638A2

ELEC CONNECTOR,4 Pin

1шт.

9

863-6020

HEX SOC SCREW,M6 x 20mm, Cl 12.9

2шт.

10

892-11006

LOCK WASHER,M6

2шт.

11

829-1406

NUT,Hex, M6 x 1, Cl 10.9

2шт.

12

388811A1

CIGAR LIGHTER

not illustrated

1шт.

13

388813A1

OUTLET

power, not illustrated

2шт.

14

279265A2

SWITCH

differential lock brake, not illustrated

1шт.

15

87541092

SWITCH

Cab Dome Lamp (Not Shown)

1шт.
