Запчасти Case IH STX325 (03-09) - FUEL INJECTION PUMP 6TAA-8304 / 6TAA-9004 EMISSIONS CERTIFIED ENGINE (03) - FUEL SYSTEM

A78001

ACCUMULATOR

consists of: Ref. 1 - 42

1шт.

AR78001

REMAN-ACCUMULATOR

accumulator, N.A. only

1шт.

AC78001

CORE-ACCUMULATOR

1шт.

1

NSS

NOT SOLD SEPARAT

BODY

1шт.

2

NSS

NOT SOLD SEPARAT

VALVE solenoid

2шт.

3

NSS

NOT SOLD SEPARAT

TAPPET

2шт.

4

NSS

NOT SOLD SEPARAT

SEAL

2шт.

5

NSS

NOT SOLD SEPARAT

PLUNGER

2шт.

6

NSS

NOT SOLD SEPARAT

SEAL

2шт.

7

NSS

NOT SOLD SEPARAT

RETAINER

2шт.

8

NSS

NOT SOLD SEPARAT

SPRING

2шт.

9

NSS

NOT SOLD SEPARAT

RETAINER

2шт.

10

NSS

NOT SOLD SEPARAT

PLUNGER

2шт.

11

NSS

NOT SOLD SEPARAT

SPRING

2шт.

12

NSS

NOT SOLD SEPARAT

SHIM

2шт.

13

NSS

NOT SOLD SEPARAT

SEAT

2шт.

14

NSS

NOT SOLD SEPARAT

PLUG

2шт.

16

J4010636

SEAL

1шт.

17

J867640

O-RING,0.07" Thk x 0.364" ID, -12, Cl 5, 75 Duro

1шт.

18

J347925

ELEC CONNECTOR

Includes: Ref. 19

1шт.

19

NSS

NOT SOLD SEPARAT

SCREEN

1шт.

20

J867043

SEAL,1.78mm Thk x 10.82mm ID

1шт.

21

J417161

HARNESS

Includes: Ref. 22

1шт.

22

J417095

CABLE CLIP

1шт.

23

NSS

NOT SOLD SEPARAT

BOLT

1шт.

24

J331002

FLANGE BOLT,Hex, M10 x 1.5 x 80mm, Gr 10.9

4шт.

A77966

KIT

consists of: Ref. 28 and 29

6шт.

28

NSS

NOT SOLD SEPARAT

SEAL

1шт.

29

NSS

NOT SOLD SEPARAT

PLUG

1шт.

30

NSS

NOT SOLD SEPARAT

SEAL

1шт.

31

NSS

NOT SOLD SEPARAT

PLUG

1шт.

A77968

KIT

consists of: Ref. 32 and 33

4шт.

32

NSS

NOT SOLD SEPARAT

SEAL

1шт.

33

NSS

NOT SOLD SEPARAT

PLUG

1шт.

J4010544

ADJUSTER

consists of: Ref. 35 - 39

1шт.

35

NSS

NOT SOLD SEPARAT

ADAPTER

1шт.

36

NSS

NOT SOLD SEPARAT

GUIDE

1шт.

37

NSS

NOT SOLD SEPARAT

SPRING

1шт.

38

NSS

NOT SOLD SEPARAT

SEAT valve

1шт.

39

J4001869

SEAL

1шт.

J4025130

KIT

pressure sensing, consists of: Ref. 41 and 42

1шт.

41

NSS

NOT SOLD SEPARAT

SENSOR

1шт.

42

J4076375

SEALING WASHER,6mm ID x 9.5mm OD x 1.9mm Thk

1шт.
