Запчасти Case IH STX325 (09-48) - WEIGHTS FRONT FRAME (09) - CHASSIS/ATTACHMENTS

1

362020A1

WEIGHT

hanger, order from machinery price list

1шт.

2

896-11020

WASHER,22mm ID x 37mm OD x 4mm Thk

22 x 37 x 4 mm

14шт.

3

827-20130

BOLT,Hex, M20 x 2.5 x 130mm, Cl 10.9

10шт.

4

363811A2

INSERT

nine-weight

2шт.

5

829-1410

NUT,M10 x 1.5, Cl 10.9

2шт.

6

369696A1

BRACKET

2шт.

7

369693A1

PLATE

retaining

2шт.

8

393235A2

PLATE

weight, right-hand

1шт.

9

627-20110

BOLT,Hex, M20 x 2.5 x 110mm, Cl 10.9, Full Thd

4шт.

10

381732A3

PLATE ASSY.

weight, left-hand

1шт.

11

257375A1

STEP

2шт.

12

905-10025

BOLT,Hex Flg, M10 x 25mm

8шт.

13

825-51410

FLANGE NUT,M10, Flg Ser

8шт.

14

405846A3

WEIGHT

45 kg (100 lb.)

1шт.

15

397818A1

GRAB RAIL

2шт.

16

896-11010

WASHER,11mm ID x 21mm OD x 2.5mm Thk

4шт.

17

828-10060

BOLT,Hex, M10 x 1.5 x 60mm, Cl 10.9

2шт.

18

229483A1

RETAINER

4шт.

19

896-15016

WASHER,17.5mm ID x 34mm OD x 5mm Thk

4шт.
