Запчасти Case IH STEIGER 620 (55.302.AV[01]) - BATTERY EQUALIZER/CONVERTER, T4B (55) - ELECTRICAL SYSTEMS

1

47603899

WIRE HARNESS

Battery Equalizer, T4B

1шт.

2

896-11006

WASHER,6.6mm ID x 12.5mm OD x 2mm Thk

12шт.

3

840-1620

SCREW,Pan, M6 x 20mm, Cl 4.8

4шт.

4

896-11008

WASHER,9mm ID x 17mm OD x 2mm Thk

3шт.

5

829-1408

NUT,Hex, M8 x 1.25, Cl 10.9

1шт.

6

84316981

ISOLATOR

Vibration Dampening

4шт.

7

47535268

BRACKET

Equalizer

1шт.

8

47489949

CONVERTER,12V To 24V

Battery Equalizer

1шт.

8

47489949R

REMAN-MODULE

Battery Equalizer

1шт.

8

47489949C

CORE-MODULE

Return Number

1шт.

9

627-6030

BOLT,Hex, M6 x 1 x 30mm, Cl 10.9, Full Thd

4шт.

10

832-10406

NUT,M6 x 1, Cl 8

4шт.

11

895-25006

WASHER,6.6mm ID x 18mm OD x 1.6mm Thk

4шт.

12

425-104

NUT,1/4"-20, Cl 5

4шт.

13

47395703

BRACKET

Equalizer

1шт.

14

627-8025

BOLT,Hex, M8 x 1.25 x 25mm, Cl 10.9, Full Thd

2шт.

15

47603908

DECAL

Fuse And Relay Location

1шт.

16

L11541

CABLE TIE,203.2mm L, Nylon

3шт.

17

L18331

CABLE TIE,375.9mm L, Nylon, Black

15"

1шт.

18

449068A1

STUD

M8

1шт.

19

84323044

THREADED INSERT,1/4" - 20

4шт.
