Артикул
Название
Примечание
Количество
1
700-446
ELBOW,45 Degree Elbow, 11/16" - 16 Male ORFS x M18 x 1.5 Male ORB
Incl 26 - 27
4шт.
2
84486319
CONTROL VALVE
Orbital, Pilot Steering, Start Serial: ZFF308001
1шт.
3
84340158
BRACKET, SUPPORTING
Support Cab
1шт.
4
84340159
BRACKET, SUPPORTING
Tube Support Frame
1шт.
5
87403324
BRACKET
Tube Mounting
2шт.
6
87436024
MOUNTING PARTS
Hose Mounting
2шт.
7
87312087
TUBE,9.52 mm OD
1шт.
8
87312089
TUBE,9.52 mm OD
1шт.
9
87312091
TUBE,9.52 mm OD
1шт.
11
84340336
TUBE
Control Tank
1шт.
12
84340338
TUBE
Control Pressure
1шт.
13
84340340
TUBE
Control Right
1шт.
14
84340342
TUBE
Control Left
1шт.
15
84206759
TUBE
Charge Pressure, Manifold To Filter
1шт.
16
84206773
TUBE
Hyd Pressure to Priority Valve
1шт.
17
84378798
HOSE ASSY.,9.53mm ID x 766mm L, SAE 100R1
Steering Control
4шт.
18
829-1408
NUT,Hex, M8 x 1.25, Cl 10.9
2шт.
19
238-6014
O-RING,0.07" Thk x 0.489" ID, -14, Cl 6, 90 Duro
1шт.
20
238-6021
O-RING,15/16 X 1 - 1/16, Cl 6
1шт.
21
895-11008
WASHER,9mm ID x 16mm OD x 1.6mm Thk
16шт.
22
627-8025
BOLT,Hex, M8 x 1.25 x 25mm, Cl 10.9, Full Thd
2шт.
23
827-8050
BOLT,Hex, M8 x 1.25 x 50mm, Cl 10.9
2шт.
24
827-8060
BOLT,Hex, M8 x 1.25 x 60mm, Cl 10.9
2шт.
25
832-10408
NUT,M8 x 1.25, Cl 8.8
6шт.
Выбрано товаров: 28
