(90.150.01) - CAB MOUNTING, NON-SUSPENSION

Запчасти Case IH STEIGER 600 (90.150.01) - CAB MOUNTING, NON-SUSPENSION (90) - PLATFORM, CAB, BODYWORK AND DECALS

Схема запчастей Case IH STEIGER 600 - (90.150.01) - CAB MOUNTING, NON-SUSPENSION (90) - PLATFORM, CAB, BODYWORK AND DECALS
2
1
1
2
5
4
4
3
home
1
4
3
3
5
5
2
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

87757853

RUBBER MOUNTING

4шт.

2

371043A1

WASHER

OD 84.00, ID 26.97, 7.94 mm Thick

4шт.

3

86505748

BOLT,Hex, M24 x 3 x 160mm, Cl 10.9

4шт.

4

86639243

NUT,M24 x 3, Cl 8

4шт.

5

896-11024

WASHER,26mm ID x 44mm OD x 5mm Thk

4шт.

6

87380071

HOSE,54.00 mm ID x 975.00 mm, SAE 20R4

Air Transfer (Not Shown)

1шт.

Выбрано товаров: 6
