(90.100.02[01]) - ENGINE HOOD LATCH (NORTH AMERICA)

Запчасти Case IH STEIGER 600 (90.100.02[01]) - ENGINE HOOD LATCH (NORTH AMERICA) (90) - PLATFORM, CAB, BODYWORK AND DECALS

Схема запчастей Case IH STEIGER 600 - (90.100.02[01]) - ENGINE HOOD LATCH (NORTH AMERICA) (90) - PLATFORM, CAB, BODYWORK AND DECALS
3
7
4
2
6
1
home
5
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

87422906

BUSHING,6.5mm ID x 19mm OD x 6.9mm L

M6

1шт.

2

84270759

LEVER

Latch

1шт.

3

84353483

LINK CONROD

Link

1шт.

4

84270752

FINGER BAR

Trigger

1шт.

5

86987940

CLEVIS PIN

Clevis

3шт.

6

844-6020

BOLT,Hvy Hex, M6 x 20mm, Cl 8.8

1шт.

7

825-2406

FLANGE NUT,M6 x 1, Cl 8.8

1шт.
