(01A-04) - HYDRAULICS - POWER SHIFT TRANSMISSION AND PTO CLUTCH LUBE, STEIGER 535

Запчасти Case IH STEIGER 535 (01A-04) - HYDRAULICS - POWER SHIFT TRANSMISSION AND PTO CLUTCH LUBE, STEIGER 535 (00) - PICTORIAL INDEX

Схема запчастей Case IH STEIGER 535 - (01A-04) - HYDRAULICS - POWER SHIFT TRANSMISSION AND PTO CLUTCH LUBE, STEIGER 535 (00) - PICTORIAL INDEX
7
3
4
8
2
6
11
06-20
06-32
06-21
06-32
06-32
08-03
08-03
08-03
08-05
06-20
06-32
1
9
5
10
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

Hose, Transmission Regulator Valve Supply, See Figure 06-32

1шт.

2

Hose, Pump To Filter, See Figure 06-32

1шт.

3

Filter, Left Hand Transmission, See Figure 08-05

1шт.

4

Cooler, Hydraulic Oil, See Figure 08-03

1шт.

5

Tube, Transmission Pump Supply, See Figure 06-32

1шт.

6

Pump, Oil, See Figure 06-32

1шт.

7

Valve Assembly, PTO Control, See Figure 06-21

1шт.

8

Tube, PTO Valve Pressure Supply, See Figure 06-20

1шт.

9

Tube, PTO Valve Lube Supply, See Figure 06-20

1шт.

10

Hose, Cooler to Axle/Transmission Filter, See Figure 08-03

1шт.

11

Hose, Axle/Transmission Filter to Cooler,See Figure 08-03

1шт.
