Запчасти Case IH STEIGER 500 (05.100.03[04]) - FILTERS & CAPACITIES, ROWTRAC 500 (05) - SERVICE & MAINTENANCE

*

REF

INSTRUCTION

Antifreeze, Engine Coolant Drain And Flush, Case IH ES COMPLEAT, 15.2 Gal (57.6 L)

1шт.

1

5801592277

FILTER

Engine Oil Filter

1шт.

*

REF

INSTRUCTION

Oil, Engine Crankcase, Case IH Akcela Unitek CJ-4, 7.2 Gal (27.25 L)

1шт.

2

84310006

AIR FILTER

Primary, Engine

2шт.

3

87356547

AIR FILTER

Secondary

2шт.

4

504209107

AIR FILTER

Engine Breather

1шт.

5

87684088

CAB FILTER,CAB

Cab

1шт.

6

87409377

FILTER

Cab Recirculated Air

1шт.

7

87408613

INSULATION

Cab Recirculation

1шт.

8

84211797

AIR FILTER

HVAC Intake, Cab Roof

1шт.

9

84196445

HYDRAULIC OIL FILTER

Spin On, 1 Required for Standard Flow, 2 Required for High Flow

1шт.

10

87408715

FILTER STRAINER

Hydraulic Tank Screen

1шт.

11

87714123

FILTER

Main Aux Valve, 100-150 Micron

1шт.

*

REF

INSTRUCTION

Hydraulic Oil, Case IH Akcela NEXPLORE, 64.5 Gal (244 L)

1шт.

If Three Point HItch Equipped, Add 5 Gal (19 L)

1шт.

*

REF

INSTRUCTION

Idler Hub (Each), SAE 50W TO 4 Oil, 12.5 oz (370 ML)

1шт.

*

REF

INSTRUCTION

Roller Hub (Each), SAE 30W Engine Oil, 7.6 oz (225 ML)

1шт.

12

84255607

HYDRAULIC OIL FILTER,Spin-on, M87 x 2.5, 98.8mm OD x 239.8mm L

Transmission Lube Filter

1шт.

*

REF

INSTRUCTION

Transmission Oil, Case IH Akcela HY-TRAN Ultra, 16.6 Gal (63 L)

1шт.

13

84303715

FUEL FILTER

w/Water Separator, Frame Mounted

1шт.

14

84597068

FUEL FILTER

Frame Mounted

1шт.

*

REF

INSTRUCTION

Grease, Chassis Lube, Akcela Multi-Purpose 251H EP, As Required

1шт.

15

84247272

FILTER,In-Line

Urea

1шт.

16

84254852

FILTER

Denox Def Kit

1шт.

17

84367903

FILTER

Element, Def

1шт.
