Запчасти Case IH STEIGER 500 (88.090.02) - DIA KIT - INSTRUCTIONAL SEAT, CLOTH (88) - ACCESSORIES

Схема запчастей Case IH STEIGER 500 - (88.090.02) - DIA KIT - INSTRUCTIONAL SEAT, CLOTH (88) - ACCESSORIES
home

Артикул

Название

Примечание

Количество

1

84313028

KIT

Instructional Seat, Cloth, Incl 2 - 15, Refer To 90.120.01

1шт.

2

249707A2

BRACKET

Instructional Seat

1шт.

3

87484465

SEAT CUSHION

Rear Cushion

1шт.

4

406682A1

FASTENER

Velcro

2шт.

5

281926A2

SAFETY BELT

Instructional Seat

1шт.

6

627-10025

BOLT,Hex, M10 x 1.5 x 25mm, Cl 10.9, Full Thd

3шт.

7

825-2410

FLANGE NUT,M10 x 1.5, Flg, Cl 8

3шт.

8

895-15006

WASHER,6.6mm ID x 25mm OD x 1.6mm Thk

2шт.

9

87484467

SEAT CUSHION

Instructional

1шт.

10

365674A1

HINGE

1шт.

11

426-412

BOLT,Hex, 1/4" - 20 x 3/4", Gr 8

3шт.

12

906051R1

HEX SOC SCREW,Btn Hd, M6 x 10mm, Cl 12.9

2шт.

13

369635A2

HOLDER

Cup

1шт.

14

394828A1

INSERT

Insert, Instructional Seat

1шт.

15

410704A1

WARNING DECAL

Instructional Seat

1шт.

Выбрано товаров: 15
