Запчасти Case IH STEIGER 500 (88.055.03) - DIA KIT - ELECTRIC ARMREST ADJUSTMENT (88) - ACCESSORIES

1

84313044

KIT

DIA, Electric Armrest Adjustment

1шт.

2

84201758

HOLDER

Motor Adapter

1шт.

3

15624411

RIVET,Flat, M6 OD x 16mm L

6X16 Flat HD Threaded Tubular Hex

2шт.

4

864-5012

HEX SOC SCREW,M5 x 12mm, Cl 8.8

3шт.

5

84235755

ELECTRIC MOTOR,12V

1шт.

6

87494094

SWITCH ASSY

Rocker, Armrest Adjust

1шт.

7

13276217

SCREW,Pozidriv Pan Hd, M6 x 16mm, Cl 5.8, Full Thd

2шт.

8

84201762

SHELL

Motor Adjust, Inside

1шт.

9

84201783

SHELL

Motor Adjust, Outside

1шт.

10

15903977

SELF-TAP SCREW,Pan Head, M4.8 x 1.6 x 19mm

4.8X19 P/HD CR-Z CST BLO

7шт.

11

84270502

HARNESS

Armrest, Electric Adjust

1шт.

12

435437A1

CABLE TIE,3/16" x 7 1/4"

CABLE STRAP

9шт.
