Артикул
Название
Примечание
Количество
1
700-305
ELBOW,90 Degree Elbow, 13/16" - 16 Male ORFS x M18 x 1.5 Male ORB
50
3шт.
2
364967A1
TEE,13/16" - 16 Male ORFS x M18 x 1.5 Male ORB x M14 x 1.5 Female ORB
ORFS STR THD 12X12XM18
1шт.
3
178889A1
DIAGNOSTIC COUPLER
Diagnostic
1шт.
4
87705053
CYLINDER,Double Acting, 50mm Rod, 526.7mm Stroke
Steering, Steiger 550 & 600, QuadTrac 550 & 600
1шт.
4
87490283
HYDRAULIC CYLINDER,Double Acting, 50mm Rod, 526mm Stroke
Steering, Steiger 500, QuadTrac 450 & 500
1шт.
5
87746906
PIN
Flag
2шт.
6
70-6076T3
PIN
Flag
2шт.
7
70-5967T1
SPACER,16.7mm ID x 22.2mm OD x 11.2mm
22 OD 17 ID 11 W
4шт.
8
84340159
BRACKET, SUPPORTING
Steering Tube Support Frame
1шт.
9
87403324
BRACKET
Hydraulic Tube Mounting
2шт.
10
87436024
MOUNTING PARTS
Bar Hose
2шт.
11
84340336
TUBE
Steering Control, Signal Tank
1шт.
12
84340338
TUBE
Steering Control, Signal Pressure
1шт.
13
84340340
TUBE
Steering Control, Signal Right
1шт.
14
84340342
TUBE
Steering Control, Signal Left
1шт.
15
84208210
TUBE
Steering Left
1шт.
16
84208212
TUBE
Steering Right
1шт.
17
84206759
TUBE
Charge Pressure, Manifold To Filter
1шт.
18
84206773
TUBE
Hydraulic Pressure To Priority Valve
1шт.
19
496-21066
WASHER,16.6mm ID x 33.5mm OD x 3.8mm Thk
4шт.
20
895-11008
WASHER,9mm ID x 16mm OD x 1.6mm Thk
16шт.
21
87563128
LOCK BOLT,Hex, M16 x 2 x 35mm, Cl 8.8, Full Thd
4шт.
22
827-8050
BOLT,Hex, M8 x 1.25 x 50mm, Cl 10.9
2шт.
23
829-1408
NUT,Hex, M8 x 1.25, Cl 10.9
2шт.
24
238-6014
O-RING,0.07" Thk x 0.489" ID, -14, Cl 6, 90 Duro
3шт.
25
238-6021
O-RING,15/16 X 1 - 1/16, Cl 6
1шт.
Выбрано товаров: 26
