Запчасти Case IH STEIGER 485 (01A-24) - HYDRAULICS - PARALLEL FLOW CIRCUITRY (00) - PICTORIAL INDEX

1

Pump Assy., Parallel Flow, See Figure 08-45

1шт.

2

Hose, Gear Pump Supply, See Figure 08-52

1шт.

3

Hose, Return, See Figure 08-52

1шт.

4

Hose, Supply, Auxiliary Valve from Gear Pump, See Figure 08-52

1шт.

5

Hose, Return, Auxiliary Valve to Filter, See Figure 08-52

1шт.

6

Hose, Load Sense, Gear Pump to Auxiliary Valve, See Figure 08-52

1шт.

7

Valve Assy., Remote Auxiliary, See Figure 08-52

1шт.

8

Filter, Parallel Flow, See Figure 08-46

1шт.

9

Hose, Drain, Gear Pump to Tank, See Figure 08-52

1шт.

10

Tube, Supply, from RH Main Filter, See Figure 08-11 & 08-14

1шт.

11

Tube, Supply, from RH Main Filter, See Figure 08-11 & 08-14

1шт.

12

Tank, Hydraulic, Wheel Tractor, See Figure 08-19

1шт.

12

Tank, Hydraulic, QUADTRAC Tractor, See Figure 08-20

1шт.

13

Filter Assy., RH Axle / Transmission Lubrication, See Figure 08-05

1шт.

14

Valve Assy., Regulator, See figure 08-15

1шт.

15

Tube, Pump Supply from Regulator, Wheeled Tractor, See Figure 08-11

1шт.

15

Tube, Pump Supply from Regulator, Quadtrac, See figure 08-14

1шт.

16

Pump, Piston, See Figure 08-28

1шт.

17

Tube / Hose Assy., Gear Pump to RH Filter, See Figure 08-25 & 08-26

1шт.

18

Hose, Case Drain, See Figure 08-25 & 08-26

1шт.

19

Tube, Change Pressure Supply, See Figure 08-25 & 08-26

1шт.

20

Tube, Gear Pump Supply, See Figure 08-25 & 08-26

1шт.

21

Hose, Return, See figure 08-25 & 08-26

1шт.
