Запчасти Case IH STEIGER 450 (88.090.07) - DIA KIT, ADDITIONAL PRODUCTS - MANUAL MIRRORS KIT (88) - ACCESSORIES

Схема запчастей Case IH STEIGER 450 - (88.090.07) - DIA KIT, ADDITIONAL PRODUCTS - MANUAL MIRRORS KIT (88) - ACCESSORIES
15
home
20
15
15
16
14
6
4
3
5
22
21
7
12
8
11
19
18
16
22
8
21
17
15
9
15
7
19
8
10
13
15
18
1

Артикул

Название

Примечание

Количество

1

84313053

KIT

DIA KIT, MANUAL MIRRORS - Incl 2 - 12

1шт.

2

84545483

INSTRUCTION

Installation (Not Shown)

1шт.

3

87363073

ARM

RH MIRROR (MANUAL)

1шт.

4

87350494

MIRROR ASSY.,240mm x 329mm

2шт.

5

84307672

BRACKET

MIRROR

2шт.

6

896-19012

WASHER,M12 x 24.5 x 3, HT

4шт.

7

514-865

BOLT,Hex, M12 x 1.75 x 80mm, Cl 10.9

4шт.

8

84401325

FOAM INSULATION

MIRROR ROOF OPENING

2шт.

9

84307675

SEAL

SEAL, MIRROR

2шт.

10

854-10050

BOLT,Hvy Hex, M10 x 50mm, Cl 10.9

8шт.

11

87363070

ARM

LH MIRROR (MANUAL) (Not Shown)

1шт.

12

245918C1

LENS

PLUG

1шт.

Выбрано товаров: 12
