1
402797A1
BRACKET
Throttle Bracket
1шт.
With Advanced Farming Systems (AFS)
1шт.
1
367607A1
BRACKET
Throttle Bracket
1шт.
With Power Shift Transmission
1шт.
2
258734A2
BRACKET
Throttle Friction Device
1шт.
3
259040A1
INSERT
Friction Device
2шт.
4
237486A1
WASHER
2шт.
5
87536486
SCREW,M4 x 0.7 x 16.01mm, Cl 12.9
M4 x 16
3шт.
6
238-6025
O-RING,0.07" Thk x 1.176" ID, -25, Cl 6, 90 Duro
1шт.
7
495-81022
WASHER,17/32" x 1 1/8" x .060"
1шт.
8
103-3350
SNAP RING,#50, .392" Dia, E-Type
1шт.
9
239491A1
BUSHING
1шт.
10
832-10406
NUT,M6 x 1, Cl 8
2шт.
11
259012A1
POTENTIOMETER,2500 Ohm
Throttle Control
1шт.
With Power Shift Transmission
1шт.
11
402751A1
POTENTIOMETER,2500 Ohm
Throttle Control
1шт.
With Manual Shift Transmission
1шт.
12
832-46404
NUT,M4 x .7, Cl 8
2шт.
13
864-4025
HEX SOC SCREW,M4 x 25mm, Cl 8.8
2шт.
14
276352A1
HARNESS
Electronic Throttle
1шт.
With Power Shift Transmission
1шт.
Manual Shift Transmission with ARU
1шт.
15
87622401
GRIP
Throttle Face Plate
1шт.
16
293388A2
GRIP
Throttle, See Figure: 06-01
1шт.
Manual Shift Transmission with ARU
1шт.
16
388705A1
GRIP
Throttle, See Figure: 06-01
1шт.
16
388864A1
GRIP
Throttle, Leather, See Figure: 06-01
1шт.
17
864-4035
HEX SOC SCREW,M4 x 35mm, Cl 8.8
2шт.
18
811-6030
CARRIAGE BOLT,Sht Sq Nk, M6 x 1 x 30mm, Cl 8.8
1шт.
19
892-11006
LOCK WASHER,M6
1шт.
