1
87350634
MUFFLER
without Spark Arrestor
1шт.
2
87430632
ELBOW
Muffler Exhuast, Inc. 3
1шт.
3
87430634
CLAMP,159.5mm ID
Muffler
1шт.
4
357686A1
ASSEMBLY
1шт.
5
87308233
EXHAUST SYSTEM PIPE,5.00", 6.00" OD
Double Wall
1шт.
6
87406903
COLLAR CLAMP
2шт.
7
87376393
EXHAUST MANIFOLD,5.03 mm ID x 5.27 mm OD x 13 mm L
Flexible
1шт.
8
87439947
BRACKET
Support
1шт.
9
87439948
U-BOLT
BOLT "U" 6"
1шт.
10
495-11034
WASHER,5/16", SAE
2шт.
11
231-1445
NUT,5/16"-18, GB
2шт.
12
87308225
ELBOW
Exhaust
1шт.
13
868-10025
12 PT SCREW,M10 x 25mm, Cl 12.9
6шт.
14
87527524
SHIELD
Debris
1шт.
15
829-1412
NUT,M12, Cl 10.9
2шт.
16
896-15012
WASHER,13.5mm ID x 28mm OD x 4mm Thk
2шт.
17
87308232
SHIELD
Heat
1шт.
18
627-10030
BOLT,Hex, M10 x 1.5 x 30mm, Cl 10.9, Full Thd
2шт.
19
896-15010
WASHER,11mm ID x 24mm OD x 3mm Thk
6шт.
20
87439927
BRACKET
Heat Shield
1шт.
21
827-10040
BOLT,Hex, M10 x 1.5 x 40mm, Cl 10.9, Full Thd
6шт.
22
829-1410
NUT,M10 x 1.5, Cl 10.9
4шт.
23
896-11010
WASHER,11mm ID x 21mm OD x 2.5mm Thk
14шт.
24
87308231
SHIELD
Manifold Heat
1шт.
25
627-10025
BOLT,Hex, M10 x 1.5 x 25mm, Cl 10.9, Full Thd
4шт.
26
811-10025
CARRIAGE BOLT,Sht Sq Nk, M10 x 1.5 x 25mm, Cl 8.8
2шт.
27
87527959
SHIELD
Support, Debris
1шт.
28
404824A1
SHIM
Muffler Mounting
1шт.
29
832-46410
NUT,M10 x 1.5, Cl 8
4шт.
30
87304384
HOSE,50.80 mm ID x 374.70 mm
Aspirator
1шт.
31
214-3240
HOSE CLAMP,1-3/4" - 2-5/8", HD Worm, W/ Liner
2шт.
