1
87306420
AFTERCOOLER
Charged Air, 19.6 FPI
1шт.
2
251400A1
BELLOWS
Tube, LH
1шт.
3
87306140
BELLOWS
Tube, RH
1шт.
4
L124635
HOSE CLAMP
4шт.
5
87303966
AIR INTAKE TUBE,3.50" OD
Charged Air, LH
1шт.
6
87439767
AIR INTAKE TUBE,88.9-101.6 mm OD x 774.7, 48.1 mm L
Charged Air, RH
1шт.
7
87340760
INTAKE AIR HOSE,88.90 mm ID x 110.00
Connector
2шт.
8
L116820
CLAMP,82.55mm - 104.78mm
Hose
4шт.
9
87304473
ELBOW
90
1шт.
10
238-6240
O-RING,0.139" Thk x 3.734" ID, -240, Cl 6, 90 Duro
1шт.
11
87304529
SPECIAL CLAMP,125mm - 129mm
T-Bolt Constant Torque
1шт.
12
832-10410
NUT,M10 x 1.5, Cl 8
2шт.
13
895-15010
WASHER,11mm ID x 24mm OD x 2mm Thk
2шт.
14
434177A1
ISOLATOR
4шт.
15
496-41041
WASHER,13/32" x 1 1/8" x .134"
2шт.
16
827-10040
BOLT,Hex, M10 x 1.5 x 40mm, Cl 10.9, Full Thd
2шт.
17
827-8110
BOLT,Hex, M8 x 1.25 x 110mm, Cl 10.9
2шт.
18
895-15008
WASHER,9mm ID x 20mm OD x 1.6mm Thk
2шт.
19
496-41034
WASHER,.344" x 1" x .098", HDN
2шт.
20
832-10408
NUT,M8 x 1.25, Cl 8.8
2шт.
