1
430739A1
BUMPER
Front Frame
1шт.
2
895-11008
WASHER,9mm ID x 16mm OD x 1.6mm Thk
5шт.
3
323295A2
SCREEN
1шт.
4
627-6016
BOLT,Hex, M6 x 1 x 16mm, Cl 10.9, Full Thd
3шт.
5
433781A1
BRACKET
Mounting, Headlamps
1шт.
6
410869A1
SEAL
Foam, Headlamp
1шт.
7
627-8025
BOLT,Hex, M8 x 1.25 x 25mm, Cl 10.9, Full Thd
5шт.
8
323383A6
SUPPORT
Bumper Screen
1шт.
9
832-10406
NUT,M6 x 1, Cl 8
3шт.
10
895-11010
WASHER,11mm ID x 20mm OD x 2mm Thk
4шт.
11
627-10020
BOLT,Hex, M10 x 1.5 x 20mm, Cl 10.9, Full Thd
2шт.
12
895-15006
WASHER,6.6mm ID x 25mm OD x 1.6mm Thk
3шт.
