Запчасти Case IH STEIGER 435 (01A-01) - HYDRAULICS - MANUAL SHIFT TRANSMISSION AND PTO CLUTCH LUBE (00) - PICTORIAL INDEX

1

Hose, Transmission Regulator Valve Supply, See Figure 06-31

1шт.

2

Hose, Pump To Filter, See Figure 06-31

1шт.

3

Filter, Left Hand Transmission, See Figure 08-05

1шт.

4

Cooler, Hydraulic Oil, See Figure 08-01

1шт.

5

Tube, Transmission Pump Supply, See Figure 06-31

1шт.

6

Hose, Cooler Supply And Outlet, See Figure 08-01

1шт.

7

Valve Assembly, PTO Control, See Figure 06-21

1шт.

8

Tube, PTO Valve Pressure Supply, See Figure 06-19

1шт.

9

Tube, PTO Valve Lube Supply, See Figure 06-19

1шт.

10

Tube, Oil Pump to Filter, See Figure 06-31

1шт.

11

Tube, Supply, Transmission Regulator Valve from Filter, See Figure 06-31

1шт.

12

Tube, Transmission Filter to Oil Pump, See Figure 06-31

1шт.
