Запчасти Case IH STEIGER 420 (25.102.AD[01]) - VAR - 424823, 424824, 424268 - FRONT AXLE CARRIER (25) - FRONT AXLE SYSTEM

1

388968A1

CARRIER

Axle, Incl 2 - 4

1шт.

2

837-12025

DOWEL,M12 x 25

2шт.

3

837-16080

DOWEL,M16 x 80

2шт.

4

837-16040

DOWEL,M16 x 40

2шт.

5

198843A1

SHIM,0.508mm Thk

1шт.

5

178555A1

SHIM,0.130mm Thk

1шт.

5

178554A1

SHIM,0.101mm Thk

1шт.

5

178553A1

SHIM,0.076mm Thk

1шт.

6

395209A1

YOKE

Front Axle, 8C

1шт.

7

255124A1

SHIM,290mm ID x 345mm OD x 0.5mm Thk

1шт.

7

255123A1

SHIM,290mm ID x 345mm OD x 0.13mm Thk

1шт.

7

255122A1

SHIM,290mm ID x 345mm OD x 0.102mm Thk

1шт.

7

255121A1

SHIM,290mm ID x 345mm OD x 0.076mm Thk

1шт.

8

828-12080

BOLT,Hex, M12 x 1.75 x 80mm, Cl 10.9

8шт.

9

828-12045

BOLT,Hex, M12 x 1.75 x 45mm, Cl 10.9, Full Thd

14шт.

10

896-12012

WASHER,13.5mm ID x 24mm OD x 3mm Thk

22шт.

11

231637A2

COVER,66 mm ID x 136 mm OD x 71.45 mm

1шт.

12

253932A1

ROLLER BEARING,119.99mm ID x 37.98mm W

1шт.

13

139060C2

SEAL,82.6mm ID x 88.6mm OD x 4.5mm Thk

Seal

1шт.

14

226492A2

SHIM,0.076mm Thk

1шт.

14

226493A2

SHIM,393mm OD x 0.1mm Thk

1шт.

14

226494A2

SHIM,393mm OD x 0.13mm Thk

1шт.

14

226496A2

SHIM,0.508mm Thk

1шт.

15

837-6055

DOWEL,M6 x 55

1шт.

16

238-5226

O-RING,0.139" Thk x 1.984" ID, -226, Cl 5, 75 Duro

1шт.

17

229553A3

TUBE

Suction

1шт.

18

139059C1

SEAL,70mm ID x 90mm OD x 8mm Thk

Axle Carrier

2шт.

19

1251958C1

WASHER,13mm ID x 25.40mm OD x 1.367mm, HTS

12шт.

20

628-12035

BOLT,Hex, M12 x 1.75 x 35mm, Cl 10.9, Full Thd

12шт.

21

84468348

TUBE

Service Brake Jumper

1шт.

22

86985628

TUBE,7.50mm ID x 11.85mm OD x 117mm L

1шт.

23

245162A1

TUBE,7mm ID x 11.85mm OD x 110.5mm Length

1шт.

24

47795329

O-RING,0.07" Thk x 0.426" ID, -13, Cl 8, Duro 90

4шт.

25

47795330

O-RING,0.07" Thk x 0.551" ID, -15, Cl 8, 90 Duro

2шт.
