Запчасти Case IH STEIGER 400 (90.154.01[01]) - LEFT HAND DOOR - INSTALLATION (90) - PLATFORM, CAB, BODYWORK AND DECALS

1

84542381

PIN,10mm OD x 98.6mm L

Headed, Door

2шт.

2

733-3220

COTTER PIN,M3.2 x 20

2шт.

3

84281206

GAS STRUT

LH Door

1шт.

4

3233348R1

CLIP

Retainer

2шт.

5

321277A1

PIN,17.2mm OD x 52mm L

Lock

1шт.

6

895-18010

WASHER,10.5mm ID x 18mm OD x 1.6mm Thk

3шт.

7

84360842

PLATE,7/16" - 14

Door Latch

1шт.
