Запчасти Case IH STEIGER 370 (55.640.BH[04]) - ISO 11783 POWER HARNESS (55) - ELECTRICAL SYSTEMS

1

47525666

WIRE HARNESS

Power Harness, ISO 11783, Incl 2 - 8

1шт.

2

84563565

FUSE HOLDER

ISO 11783 PDM, C850

1шт.

2

47563654

ELEC CONNECTOR

ISO 11783 PDM, C850

1шт.

2

47530550

ELEC. TERMINAL PIN

Lock, ISO 11783 PDM, C850

2шт.

2

47530551

ELEC. TERMINAL PIN

Lock, ISO 11783 PDM, C850

2шт.

2

84539290

RELAY,12V, 50A

50A, ISO 11783 PDM, C850

2шт.

2

338057A1

FUSE,50A, Maxival, Red

ISO 11783 PDM, C850

1шт.

2

338054A1

FUSE,20A, Maxival, Yellow

ISO 11783 PDM, C850

1шт.

2

84577566

TERMINAL

ISO 11783 PDM, C850

2шт.

2

84577567

TERMINAL

ISO 11783 PDM, C850

2шт.

2

84574199

TERMINAL

ISO 11783 PDM, C850

4шт.

2

84574203

TERMINAL

ISO 11783 PDM, C850

4шт.

2

47563644

ELEC. TERMINAL PIN

Seal, ISO 11783 PDM, C850

1шт.

2

84574205

SEAL

ISO 11783 PDM, C850

4шт.

2

47563638

ELEC. TERMINAL PIN

ISO 11783 PDM, C850

2шт.

2

47563633

ELEC. TERMINAL PIN

Seal, ISO 11783 PDM, C850

1шт.

2

84574204

SEAL

ISO 11783 PDM, C850

4шт.

3

84140737

TERMINAL CONNECTOR

Negative JSS, C866

1шт.

4

84426139

TERMINAL

Negative JSS, C867

1шт.

5

382255A1

TERMINAL CONNECTOR

12V Positive JSS, C861

1шт.

6

87706435

TERMINAL CONNECTOR

To ISO 11783 Chassis Harness, C865F

1шт.

6

87697948

ELEC. TERMINAL PIN,Male, 5 - 8 mm2

To ISO 11783 Chassis Harness, C865F

1шт.

7

87382922

WIRE CONNECTOR,Female, 10 Cavities

To ISO 11783 Chassis Harness, C860F

1шт.

7

84279937

PLUG,Apex, 2.80mm

To ISO 11783 Chassis Harness, C860F

1шт.

7

84395356

TERMINAL,Female, 2.8mm, 18-20

To ISO 11783 Chassis Harness, C860F

7шт.

7

84294640

TERMINAL

To ISO 11783 Chassis Harness, C860F

2шт.

8

87581779

ELEC CONNECTOR,Female, 1 Cavity

To ISO 11783 Chassis Harness, C864M

1шт.

8

84819143

TERMINAL CONNECTOR,Female, 4.5 - 8 mm2

To ISO 11783 Chassis Harness, C864M

1шт.
