1
D121972
ALARM
Backup
1шт.
Reference Figure 88.100.09 for DIA Kit
1шт.
2
84195225
BRACKET
Alarm Mount
1шт.
3
896-11006
WASHER,6.6mm ID x 12.5mm OD x 2mm Thk
8шт.
4
627-6020
BOLT,Hex, M6 x 1 x 20mm, Cl 10.9, Full Thd
4шт.
5
829-1406
NUT,Hex, M6 x 1, Cl 10.9
4шт.
6
22-824
CABLE TIE,3/16" x 7 1/4"
2шт.
7
391364A1
HARNESS
Backup Alarm - Incl 11
1шт.
8
87022684
BOLT,Hex, M12 x 45mm, Cl 10.9
2шт.
9
896-11012
WASHER,13.5mm ID x 24mm OD x 3mm Thk
4шт.
10
832-10412
NUT,M12 x 1.75, Cl 8
M12
2шт.
11
222136A1
ELEC CONNECTOR,Male, 2 Pin
To Rear Frame Harness
1шт.
