Запчасти Case IH STEIGER 335 (01A-12) - CHARGE PUMP AND AUXILIARY REMOTE CIRCUIT WITH STANDARD HYDRAULICS (00) - PICTORIAL INDEX

1

VALVE, Priority / EHPS, See Figure 08-12

1шт.

2

HOSE, Priority Valve Supply, See Figures 08-17

1шт.

3

HOSE, Pump Load Sense, See Figures 08-17

1шт.

4

HOSE, Case Drain, See Figures 08-17

1шт.

5

TUBE, Charge Pressure Supply, See Figures 08-17

1шт.

6

HOSE, Return, See Figures 08-17

1шт.

7

HOSE, Auxiliary Remote Valve Supply, See Figures 08-27

1шт.

8

Filter Assy., RH Axle / Transmission Lubrication, See Figure 08-03

1шт.

9

HOSE, Auxiliary Remote Load Sense, See Figures 08-27

1шт.

10

HOSE, Gear Pump Pilot Pressure, Electronic Remotes, See Figure 08-27

1шт.

11

HOSE, Auxiliary Remote Return, See Figures 08-27

1шт.

12

FILTER, Main Hydraulic (Below Battery) See Figure 08-04

1шт.

13

VALVE, Regulator, See Figure 08-11

1шт.

14

HOSE, Pilot Pressure, Return To Rear Axle, See Figures 08-07

1шт.

15

PUMP, Piston, See Figure 08-19

1шт.

16

HOSE, Charge Pump Outlet to RH Filter, See Figures 08-17

1шт.

17

PUMP, Gear, See Figure 08-26

1шт.

18

TUBE, Gear Pump Supply, See Figures 08-17

1шт.

19

ELBOW, 90, Pilot Pressure, Return to Rear Axle, See Figure 08-27

1шт.

20

TANK, Hydraulic, See Figure 08-16

1шт.

21

TUBE, Piston Pump Supply from Regulator, See Figure 08-09

1шт.

22

HOSE, Piston Pump Supply from Regulator, See Figure 08-17

1шт.

23

TUBE, EF Supply to Remote Auxiliary Valve, See Figure 08-21

1шт.

24

BRACKET, Mounting, EHPS / Priority Valve, See Figure 08-21

1шт.

25

Filter Assy., RH Axle / Transmission Lubrication, See Figure 08-03

1шт.
