Артикул
Название
Примечание
Количество
1
700-445
TEE,13/16" - 16 Male ORFS x 13/16" - 16 Male ORFS x M22 x 1.5 Male ORB
Inc. 2 & 3
2шт.
2
637-63193
O-RING,2.2mm Thk x 19.3mm ID, Cl 6, 90 Duro
3шт.
4
360200A2
HOSE ASSY.
1905 mm (75"), to Rear Axle Park Brake Port
1шт.
5
327479A2
HOSE
1720 mm (67"), Front Axle to Rear Axle
1шт.
6
701-423
TEE,13/16" - 16 Male ORFS x 13/16" - 16 Male ORFS x 13/16" - 16 Male ORFS
Inc. 7
1шт.
7
87366186
HYD TUBE,12.6 mm ID x 15.9 mm OD x 1000, 300 mm L
Brake Supply
1шт.
8
392427A1
HOSE ASSY.
1947 mm (76-1/2"), Brake Valve to Regulator Valve
1шт.
9
700-115
HYD CONNECTOR,1" - 14 Male ORFS x M18 x 1.5 Male ORB
Inc. 10 & 11
2шт.
10
238-6016
O-RING,0.07" Thk x 0.614" ID, -16, Cl 6, 90 Duro
7шт.
11
637-63153
O-RING,2.2mm Thk x 15.3mm ID, Cl 6, 90 Duro
2шт.
12
700-103
HYD CONNECTOR,1" - 14 Male ORFS x M22 x 1.5 Male ORB
Incl. 2 & 10
1шт.
13
87329133
HOSE
Return
1шт.
14
515-22159
CLAMP,5/8", Insul, 5/16" Bolt
2шт.
15
701-919
BHD LOCK NUT,1" - 14
1шт.
16
515-23206
CLAMP,13/16", Insul, 3/8" Bolt
P-type
2шт.
17
627-8020
BOLT,Hex, M8 x 1.25 x 20mm, Cl 10.9, Full Thd
2шт.
18
87672094
VALVE
Regulator, See Figure: 08-11
1шт.
19
827-10150
BOLT,Hex, M10 x 1.5 x 150mm, Cl 10.9
3шт.
20
449827A2
TUBE
Regulator Valve to Mounting Plate
1шт.
21
701-903
NUT,13/16" - 16
2шт.
22
449796A1
TUBE
Tow Valve to Mounting Plate Tee
1шт.
23
701-301
ELBOW,90 Degree Elbow, 13/16" - 16 Male ORFS x 13/16" - 16 Male ORFS
Incl. 3
1шт.
24
87310422
BRACKET
Mounting, Tube
1шт.
25
449798A1
TUBE
Tow Valve to Mounting Plate Tee
1шт.
26
701-320
ELBOW,90 Degree Elbow, 13/16" - 16 Male ORFS x 13/16" - 16 Female ORFS
Incl. 3
1шт.
27
349863A2
CABLE
Tow Valve, See Figure: 08-15 for Mounting & Parts
1шт.
28
87679712
VALVE
Control, Tow Block, See Figure: 08-14
1шт.
29
361897A1
SPRING
Tow Valve
1шт.
30
449830A1
PLATE ASSY.
Mounting, Tow Valve
1шт.
31
392748A1
SPACER
2шт.
32
242-4412
CHAIN LINK
Tow Valve Arm
1шт.
33
390918A3
ARM
Tow Valve
1шт.
34
827-6070
BOLT,Hex, M6 x 70mm, Cl 10.9
1шт.
37
829-1412
NUT,M12, Cl 10.9
3шт.
38
327484A2
HOSE ASSY.
1033 mm (40-1/2")
1шт.
39
829-1408
NUT,Hex, M8 x 1.25, Cl 10.9
5шт.
40
701-429
TEE,1" - 14 Male ORFS x 1" - 14 Male ORFS x 1" - 14 Male ORFS
Inc. 10
1шт.
41
416282A1
TUBE
Jumper, Front Axle
1шт.
42
895-11008
WASHER,9mm ID x 16mm OD x 1.6mm Thk
5шт.
43
895-18010
WASHER,10.5mm ID x 18mm OD x 1.6mm Thk
3шт.
44
896-12016
WASHER,17.5mm ID x 30mm OD x 4mm Thk
1шт.
178889A1
DIAGNOSTIC COUPLER
Diagnostic, Inc. 45 & 47
1шт.
45
NSS
NOT SOLD SEPARAT
Fitting, Diagnostic, Inc. 46
1шт.
46
637-63113
O-RING,2.2mm Thk x 11.3mm ID, Cl 6
3шт.
47
H434163
DUST CAP
1шт.
48
416276A1
TUBE
Jumper, Rear Axle
1шт.
341195A1
ORIFICE
Inc. 3, 46, 49 & 50
2шт.
49
NSS
NOT SOLD SEPARAT
Connector, 13/16" fcsl x M14 orb
2шт.
50
NSS
NOT SOLD SEPARAT
Screw, Set, Hex Soc. M8 x 12, Cup Pt.
1шт.
