Запчасти Case IH STEIGER 335 (05-12) - CYLINDER ASSY - ARTICULATION, WITHOUT SENSOR (05) - STEERING

1

410700A1

KNUCKLE JOINT

2шт.

2

D95142

WIPER SEAL,1.5" ID x 2" OD x 0.31" Thk

8шт.

3

87447988

PIN

2шт.

4

87447987

PLATE

2шт.

5

627-12025

BOLT,Hex, M12 x 1.75 x 25mm, Cl 10.9, Full Thd

4шт.

6

937781R92

HOSE,3.02mm ID x 686mm L

Lubrication

1шт.

7

86637724

PLUG,1/8" - 27 NPT

2шт.

8

219-36

LUBE NIPPLE,45 Degree Elbow, 1/8" - 27 NPTF

1шт.

9

217-1014

ELBOW,1/8" - 27 Female x 1/8" - 27 Male

1шт.

10

F53473

LOCK NUT,1/8-27 NPSM

1шт.

11

86636814

LUBE NIPPLE,1/4"-28 x .52" lg

1шт.

87304291

STEERING CYLINDER,Double Acting, 50mm Rod, 743mm Stroke

Articulation, Inc. 13 - 27 - REPLACES P/N 87447305 which includes items 29 - 33 (Service Parts)

1шт.

87304291R

REMAN-HYD CYLINDER

STEIGER 335 4WD TRACTOR, Articulation (8/07-)

1шт.

87304291C

CORE-HYD CYLINDER

Return Number

1шт.

13

87397787

CASE

Barrel

1шт.

14

87378379

COVER

End Cap

1шт.

15

NSS

NOT SOLD SEPARAT

Ring

1шт.

16

NSS

NOT SOLD SEPARAT

O-Ring

1шт.

17

NSS

NOT SOLD SEPARAT

Seal

2шт.

18

NSS

NOT SOLD SEPARAT

Wiper

2шт.

19

87378385

ROD

Piston

1шт.

20

87378376

PISTON

1шт.

21

877-20818

SET SCREW,Hex Skt, M8 x 18mm, Cone Pt

1шт.

22

NSS

NOT SOLD SEPARAT

O-Ring

1шт.

23

NSS

NOT SOLD SEPARAT

Ring, Piston

1шт.

24

NSS

NOT SOLD SEPARAT

Seal, Piston

1шт.

25

NSS

NOT SOLD SEPARAT

Ring, Wear

2шт.

26

87378388

BUSHING

Wear

1шт.

27

87378378

WASHER

End Cap

1шт.

28

87377669

SEAL KIT

Seals, Inc. 15 - 18, 22 - 26

1шт.

29

87397773

PISTON

Articulation Cylinder (Not Shown) REPLACED By P/N 87304291

1шт.

30

87397782

HEAD

Steering Cylinder (87447305) (Not Shown)

1шт.

31

87397786

SHAFT

Steering Cylinder (87447305) (Not Shown)

1шт.

32

87397787

CASE

Sterring Cylinder (87447305) (Not Shown)

1шт.

33

387654A1

SEAL KIT

for Steering Cyinder 87447305 (Not Shown)

1шт.
