Артикул
Название
Примечание
Количество
1
341574A4
BRACKET
Mounting, Rear Skirt
1шт.
2
895-11008
WASHER,9mm ID x 16mm OD x 1.6mm Thk
1шт.
3
829-1408
NUT,Hex, M8 x 1.25, Cl 10.9
1шт.
4
403325A2
FOAM,30mm x 50mm x 250mm
4шт.
5
87534631
SKIRT
Rear
1шт.
6
87357990
SKIRT COVER
Left-Hand
1шт.
7
87342106
SKIRT COVER
Left-Hand, With Lower Front Wiper
1шт.
8
87357991
SKIRT COVER
Right-Hand
1шт.
9
87342107
SKIRT COVER
Right-Hand, With Lower Front Wiper
1шт.
10
361191A1
GROMMET
4шт.
11
896-15016
WASHER,17.5mm ID x 34mm OD x 5mm Thk
4шт.
12
627-16035
BOLT,Hex, M16 x 2 x 35mm, Cl 10.9, Full Thd
4шт.
13
181240A2
GLASS
Rear
1шт.
14
87436557
TINTED GLASS
Windshield
1шт.
14
87436560
TINTED GLASS
Laminated (Europe Only)
1шт.
15
87543673
SPACER
52шт.
16
117707A3
CLAMP
Window
7шт.
17
895-11008
WASHER,9mm ID x 16mm OD x 1.6mm Thk
8шт.
18
829-1408
NUT,Hex, M8 x 1.25, Cl 10.9
8шт.
19
259462A1
FOAM INSULATION
1525 mm (60")
1шт.
21
840-2820
SCREW,Pan, M8 x 20mm, Cl 4.8
4шт.
22
404882A1
SPRING NUT,M6
M6, Clip Nut
6шт.
23
355716A3
FOAM
Accoustical, Cab Roof
1шт.
24
364156A1
BRACKET
Roof Support
4шт.
25
829-1408
NUT,Hex, M8 x 1.25, Cl 10.9
8шт.
26
895-15008
WASHER,9mm ID x 20mm OD x 1.6mm Thk
8шт.
27
627-8025
BOLT,Hex, M8 x 1.25 x 25mm, Cl 10.9, Full Thd
4шт.
28
832-10408
NUT,M8 x 1.25, Cl 8.8
4шт.
29
840-1625
SCREW,Pan, M6 x 25mm, Cl 4.8
10шт.
31
353-406
PLUG,Dome, .625" hole, Nylon
If Used
1шт.
Used without AFS Option
1шт.
32
404287A1
INSERT,M6
4шт.
33
NSS
NOT SOLD SEPARAT
Roof Assy, See Figure: 09-16
1шт.
34
895-15006
WASHER,6.6mm ID x 25mm OD x 1.6mm Thk
4шт.
35
60-5021T1
SPACER,0.282" ID x 0.500" OD x 0.312" Thk
2шт.
36
60-6840T1
GROMMET,1/2" ID x 3/4" OD
2шт.
Выбрано товаров: 38
