Артикул
Название
Примечание
Количество
1
87304295
CYLINDER,Double Acting, 50mm Rod, 293.3mm Stroke
Lift, Three Point Hitch, See Figure: 08-38
2шт.
87304295R
REMAN-HYD CYLINDER
STEIGER 280, STEIGER 330 Both ASN Z6F105001 ; STX280, STX330 Both BTW Z6F100023 - Z6F105001
2шт.
87304295C
CORE-HYD CYLINDER
Return Number
1шт.
2
700-412
TEE,13/16" - 16 Male ORFS x 13/16" - 16 Male ORFS x M18 x 1.5 Male ORB
Inc. 3 and 4
1шт.
3
238-6014
O-RING,0.07" Thk x 0.489" ID, -14, Cl 6, 90 Duro
2шт.
4
637-63153
O-RING,2.2mm Thk x 15.3mm ID, Cl 6, 90 Duro
1шт.
5
700-305
ELBOW,90 Degree Elbow, 13/16" - 16 Male ORFS x M18 x 1.5 Male ORB
Incl. 6 and 7
4шт.
6
238-6014
O-RING,0.07" Thk x 0.489" ID, -14, Cl 6, 90 Duro
4шт.
7
637-63153
O-RING,2.2mm Thk x 15.3mm ID, Cl 6, 90 Duro
4шт.
8
403207A1
TUBE
Return
1шт.
9
360496A1
HOSE ASSY.
Cylinder Supply, 505 mm (20")
2шт.
10
700-445
TEE,13/16" - 16 Male ORFS x 13/16" - 16 Male ORFS x M22 x 1.5 Male ORB
Inc. 11 and 12
1шт.
11
637-63193
O-RING,2.2mm Thk x 19.3mm ID, Cl 6, 90 Duro
1шт.
12
238-6014
O-RING,0.07" Thk x 0.489" ID, -14, Cl 6, 90 Duro
2шт.
13
515-23206
CLAMP,13/16", Insul, 3/8" Bolt
P-type
4шт.
14
627-8016
BOLT,Hex, M8 x 1.25 x 16mm, Cl 10.9, Full Thd
1шт.
15
895-11008
WASHER,9mm ID x 16mm OD x 1.6mm Thk
5шт.
16
700-103
HYD CONNECTOR,1" - 14 Male ORFS x M22 x 1.5 Male ORB
Inc. 17 & 18
1шт.
17
637-63193
O-RING,2.2mm Thk x 19.3mm ID, Cl 6, 90 Duro
1шт.
18
238-6016
O-RING,0.07" Thk x 0.614" ID, -16, Cl 6, 90 Duro
1шт.
19
371018A2
HOSE ASSY.
Return, 3166 mm (124-1/2")
1шт.
20
360495A2
HOSE ASSY.
Return, 1275 mm (50")
1шт.
21
360497A3
HOSE ASSY.
Pressure Line, 1380 mm (54")
1шт.
22
238-6016
O-RING,0.07" Thk x 0.614" ID, -16, Cl 6, 90 Duro
1шт.
23
515-24302
CLAMP,1 3/16", Insul, 7/16" Bolt
1шт.
24
627-8030
BOLT,Hex, M8 x 1.25 x 30mm, Cl 10.9, Full Thd
2шт.
25
829-1408
NUT,Hex, M8 x 1.25, Cl 10.9
2шт.
26
86020623
SLEEVE
Protective
1шт.
27
L18331
CABLE TIE,375.9mm L, Nylon, Black
CABLE STRAP
3шт.
Выбрано товаров: 29
