Артикул
Название
Примечание
Количество
1
700-162
HYD CONNECTOR,13/16" - 16 Male ORFS x M22 x 1.5 Male ORB
Inc. 2 and 3
1шт.
2
238-6014
O-RING,0.07" Thk x 0.489" ID, -14, Cl 6, 90 Duro
9шт.
3
637-63193
O-RING,2.2mm Thk x 19.3mm ID, Cl 6, 90 Duro
1шт.
4
360201A4
HOSE ASSY.
1925 mm (75-1/2"), Air/Lube Pump to Rear Axle
1шт.
5
388391A1
HOSE ASSY.
1697 mm (66-13/16"), Air/Lube Pump to Rear Axle
1шт.
6
627-8025
BOLT,Hex, M8 x 1.25 x 25mm, Cl 10.9, Full Thd
2шт.
7
416278A1
TUBE
Drain, Rear Axle
1шт.
8
701-903
NUT,13/16" - 16
3шт.
9
214-1420
HOSE CLAMP,#20, 0.81" - 1.75", Type F Worm
6шт.
10
337545A1
HYD CONNECTOR
Axle Drain
2шт.
11
370250A1
HOSE
990 mm (39"), Cut From S118383, Drain, Rear Axle
1шт.
12
87347801
TUBE,25.40 mm OD
Drain, Rear Axle
1шт.
13
87386393
HOSE
660 mm (32"), Cut From 31-2755, Drain, Rear Axle
1шт.
14
352734A1
HYD CONNECTOR
Axle Discharge
1шт.
15
406045A1
HOSE ASSY.
394 mm (15-1/2")
1шт.
16
87672094
VALVE
Regulator, See Figure: 08-11
1шт.
17
700-169
HYD CONNECTOR,13/16" - 16 Male ORFS x M16 x 1.5 Male ORB
Inc. 18 and 19
1шт.
18
87307521
TUBE,9.40 mm ID x 12.70 mm OD
1шт.
19
637-63133
O-RING,2.2mm Thk x 13.3mm ID, Cl 6, 90 Duro
1шт.
20
413338A1
TUBE
1шт.
21
449800A1
TUBE
1шт.
22
700-102
HYD CONNECTOR,13/16" - 16 Male ORFS x M18 x 1.5 Male ORB
Incl. 2 and 24
1шт.
23
700-447
TEE,13/16" - 16 Male ORFS x 13/16" - 16 Male ORFS x M22 x 1.5 Male ORB
Inc. 2, 24
1шт.
24
637-63153
O-RING,2.2mm Thk x 15.3mm ID, Cl 6, 90 Duro
3шт.
25
87307544
TUBE,9.40 mm ID x 12.70 mm OD x 43.00, 64.23 mm L
1шт.
26
201-305
ELBOW,90 Degree Elbow, 13/16" - 16 Male ORFS x 3/4" - 16 Male ORB
1/2 or x 13/16 fc sl, Incl. 2, 27
4шт.
27
637-63093
O-RING,2.2mm Thk x 9.3mm ID, Cl 6, 90 Duro
1шт.
28
701-121
UNION,13/16" - 16 Male ORFS x 13/16" - 16 Male ORFS
Inc. 2
2шт.
29
71100209
PLUG,Hex Soc, 3/4"-16 ORB
Incl 45
1шт.
30
895-11008
WASHER,9mm ID x 16mm OD x 1.6mm Thk
10шт.
31
829-1408
NUT,Hex, M8 x 1.25, Cl 10.9
10шт.
32
419605A1
TUBE
1шт.
33
50-2533T1
PLATE
4шт.
34
449813A2
TUBE
Air/Lube Pump to Front Axle
1шт.
35
449815A2
TUBE
Air/Lube Pump to Rear Axle
1шт.
36
701-301
ELBOW,90 Degree Elbow, 13/16" - 16 Male ORFS x 13/16" - 16 Male ORFS
Incl. 2
1шт.
37
515-22254
CLAMP,1", Insul, 5/16" Bolt
1шт.
38
387840A1
SLEEVE
Protective
1шт.
39
86991772
TUBE,8 mm OD
Pinion Lube
1шт.
40
8500571
SPACER,10mm ID x 25.4mm OD x 25mm L
1шт.
41
358915A1
BRACKET
1шт.
42
627-8020
BOLT,Hex, M8 x 1.25 x 20mm, Cl 10.9, Full Thd
1шт.
43
50-2551T1
CLAMP
6шт.
44
392690A1
COUPLING
Diagnostic, Inc. 24
1шт.
45
237-6012
O-RING,0.116" Thk x 0.924" ID, -912, Cl 6, 90 Duro
1шт.
46
399032A1
CAP
Dust
1шт.
48
86991773
HYD TUBE,9.52 mm OD x 56.78, 36.875 mm L
Pinion Lube
1шт.
49
31-2757
HOSE,1.00" ID x 4.00"
2шт.
50
701-320
ELBOW,90 Degree Elbow, 13/16" - 16 Male ORFS x 13/16" - 16 Female ORFS
Incl. 2
1шт.
51
86985637
FITTING
Orificed
2шт.
52
434727A1
MOTOR-PUMP
Axle Air/Lube
1шт.
53
238-6012
O-RING,0.07" Thk x 0.364" ID, -12, Cl 6, 90 Duro
3шт.
54
408000A1
HOSE
609 mm (24 in.), Cut From 31-2755
1шт.
55
419607A1
TUBE
1шт.
56
515-23270
CLAMP,1 1/16", Insul, 3/8" Bolt
2шт.
57
S120426
TUBE
Protective
1шт.
58
L18331
CABLE TIE,375.9mm L, Nylon, Black
CABLE STRAP Hose
4шт.
59
238-6011
O-RING,0.07" Thk x 0.301" ID, -11, Cl 6, 90 Duro
1шт.
60
700-153
HYD CONNECTOR,9/16" - 18 Male ORFS x M14 x 1.5 Male ORB
Inc. 58 & 59
2шт.
61
637-63113
O-RING,2.2mm Thk x 11.3mm ID, Cl 6
1шт.
62
1-4571
HOSE
114 mm (4-1/2"), Cut from 1-4480T1
1шт.
64
87368178
TUBE,38.1 mm OD
Return
1шт.
65
238-6016
O-RING,0.07" Thk x 0.614" ID, -16, Cl 6, 90 Duro
1шт.
Выбрано товаров: 65
