Запчасти Case IH STEIGER (02-12) - CONSOLE AND DASH WIRING, SERIES I (06) - ELECTRICAL

1

22-107

LAMP

LIGHT, warning

2шт.

22-667

BULB

(For 22-107)

2шт.

2

22-29

LIGHT, interior

2шт.

3

22-24

SWITCH

7шт.

4

RADIOS (See cab section)

1шт.

5

25-18

EVAPORATOR, A/C (Optional)

1шт.

6

24-28

BLOWER, air (Not needed with A/C)

1шт.

7

22-252

HARNESS, console wiring (Tiger)

1шт.

22-143

HARNESS, console wiring (Cougar)

1шт.

8

29-48

GAUGE

oil temp.

1шт.

9

29-60

GAUGE

fuel level

1шт.

10

22-84

LIGHT

dash

2шт.

11

29-47

GAUGE

oil pressure

1шт.

12

29-49

GAUGE

water temp.

1шт.

13

22-108

FLASHER UNIT

FLASHER

1шт.

14

22-309

WIRE, jumper

1шт.

15

29-27

SWITCH

safety shutdown

1шт.

16

22-389

COVER

WIRE, safety switch to hr. meter

1шт.

17

22-125

WIRE, jumper

1шт.

18

22-370

WIRE, jumper

1шт.

19

29-28

AMMETER

1шт.

20

22-70

SWITCH

blower

1шт.

21

22-142

WIRE

1шт.

22

22-371

WIRE

1шт.

23

22-140

WIRE

1шт.

24

22-139

WIRE

1шт.

25

22-141

WIRE

1шт.

26

22-118

SWITCH

heat-start (Cougar I, Cat #8S713)

1шт.

22-31

SWITCH

START BUTTON (Tiger I)

1шт.

27

22-126

HARNESS, dash (Cougar I)

1шт.

22-253

HARNESS, dash (Tiger I)

1шт.

28

22-26

FUSE

20 amp

1шт.

29

22-25

BLOCK

FUSE BLOCK

1шт.

30

22-254

HARNESS, fuse block (Tiger I)

1шт.

22-127

HARNESS, fuse block (Cougar I)

1шт.

31

22-12

SWITCH

ign.

1шт.

32

22-123

WIRE

1шт.

33

29-23

HOURMETER

HOUR METER

1шт.

34

22-386

WIRE

1шт.

35

22-121

WIRE

1шт.
