Запчасти Case IH STEIGER (03-09) - ROTARY COMPRESSOR MOUNTING GROUP (03) - Climate Control

1

COMPRESSOR (See compressor parts for usage)

1шт.

2

6-66

SET OF BELTS,0.50" W x 41.00" L

V-Belt (Tiger, used w/Refs. 9 & 17) 0.50" W x 41.00" L

1шт.

Ref: 2 06-066 belt is for S/N 30104 & below

1шт.

6-1453

V-BELT,0.53" W x 44.50" L

(Tiger, used w/Ref. 19) 0.53" W x 44.50" L

1шт.

06-1453 belt is for S/N 30105 & Up

1шт.

6-1473

V-BELT,0.67" W x 38.33" L

(Panther) 0.67" W x 38.33" L

1шт.

6-24

V-BELT,61.00" L

(Cougar w/0333) 61.00" L

1шт.

6-1428

V-BELT,0.53" W x 46.00" L

(Cougar w/3306) 0.53" W x 46.00" L

1шт.

3

19-455

NUT

10 MM

3шт.

4

19-108

WASHER,7/16"

flat, 7/16

3шт.

5

19-454

SCREW,Hex, M10 x 34mm, Cl 8.8

BOLT, 10 MM x 34 MM

3шт.

6

25-194

SHIELD, dust, 5-1/4" (Cougar & Tiger) 1/4"-28, G5, Thk

1шт.

25-372

SHIELD

dust, 6" (Panther)

1шт.

7

19-467

LOCK WASHER,Ext Tooth, 1/4"

LOCKWASHER, 1/4 EXT Tooth

3шт.

8

19-417

BOLT,Hex, 1/4" - 20 x 0.50", Gr 5, Full Thd

CAPSCREW, 1/4 x 1/2 UNC

3шт.

9

45-128

MOUNT (See note)

1шт.

10

19-17

BOLT,Hex, 3/8" - 16 x 1", Gr 5, Full Thd

CAPSCREW, 3/8 x 1 UNC

4шт.

11

19-117

LOCK WASHER,3/8"

3/8"

4шт.

12

19-107

WASHER

3/8" Flat

4шт.

13

45-137

TIGHTNER, belt

1шт.

14

14-153

SEAL

BRACKET

1шт.

15

19-542

BOLT,7/16" - 14 x 4 1/4", Gr 5

CAPSCREW, 7/16 x 4-1/2 UNC

1шт.

16

45-150

ADJUSTING STRAP

1шт.

17

45-149

MOUNT, compressor (See note)

1шт.

18

19-799

BOLT,Hex, 3/8" - 16 x 1 1/4", Gr 8

CAPSCREW, 3/8 x 1-1/4 UNC gr 8

4шт.

19

45-168

MOUNT, compressor (See note)

1шт.

Ref: 19 Mount, compressor for S/N 30189 & up.

1шт.

20

19-543

BOLT,Hex, 1/2" - 13 x 1 1/2", Gr 8

CAPSCREW, 1/2 x 1-1/2 UNC

2шт.

21

19-119

LOCK WASHER,1/2"

1/2"

2шт.

22

55-177

MOUNT, compressor

1шт.

23

19-81

NUT,1/2"-13, G5

1/2" UNC

1шт.

24

19-596

WASHER

SPACER

1шт.

25

19-109

WASHER,1/2"

FLAT WASHER

1шт.

26

232-4136

LOCK NUT,3/8"-16, GC

NUT, 3/8 UNC

2шт.

27

55-130

MOUNT, compressor (0333 Engine)

1шт.

6-1459

NO LONGER SERVICED

MOUNT, compressor (3306 Engine)

1шт.

28

19-17

BOLT,Hex, 3/8" - 16 x 1", Gr 5, Full Thd

CAPSCREW, 3/8 x 1 UNC

2шт.

29

19-48

BOLT,Hex, 1/2" - 13 x 3", Gr 5

CAPSCREW, 1/2 x 3 UNC

1шт.
