Запчасти Case IH STEIGER (01-34) - THROTTLE CONTROL ASSEMBLY (10) - CAB

60-2035T94

CONTROL

THROTTLE CONTROL ASSY, consists of 1-7

1шт.

1

60-1385T93

CONTROL

THROTTLE CONTROL

1шт.

2

60-1562T3

LARGE PLATE

PLATE

1шт.

3

9419000

BOLT,Hex, 1/4" - 20 x 1/2", Gr 5, Full Thd

CAPSCREW (see note)

2шт.

4

19-6082

JAM NUT

JAM NUT (see note)

2шт.

5

19-873

CLEVIS

1шт.

6

19-874

CLEVIS PIN,3/16" x .580"

1шт.

7

19-5380

PIN

HAIR PIN

1шт.

60-2486T91

KNOB

ASSY, consists of 8-9

1шт.

8

60-2050T2

KNOB

1шт.

9

19-5798

SET SCREW

1шт.

10

19-308

NUT,#10 - 32

1шт.

11

60-2841T1

CABLE

THROTTLE CABLE (Cat 3406 engine)

1шт.

60-2840T1

CABLE

THROTTLE CABLE (Cummins 855 engine)

1шт.

12

60-2033T2

SHIM

1шт.

13

31-1838

CLAMP

1шт.

14

153424

SCREW,Cross Fil Hd, #10 - 32 x 0.50", Gr 2

MACHINE SCREW

2шт.

15

9411893

LOCK NUT,#10-32, GB

2шт.
